From a minute to a second: where the time to build t27 went, and where it still goes

2026-10-11 · 8 min read

[measured on one 8-core Mac whose load varied overnight; pairs taken under the same load] One overnight loop measured every place t27 builds and waits, and fixed what the numbers pointed at. A warm t27c frontier went from 55-68 s to about 0.9 s, an unchanged bitstream is found in 0.22-0.39 s instead of 4.3-8.9 s, a board run after approval no longer builds first, and the corpus suite CI runs on every pull request dropped from 221-257 s to 108-140 s. Almost all of the old time went into recomputing what had not changed and into running independent work one item at a time. What is left: about 2 s per spec in zig's relink, 27 s of nextpnr per logic change, about 14 s to load a board, and a 72 s C-header gate.

Title card, no illustration yet, for: From a minute to a second: where the time to build t27 went, and where it still goes — View the title card at full size

#t27#Measurement#FPGA#Verification

Overnight from 10 to 11 October, one loop went through every place t27 builds something and makes its author wait, measured each one, and changed what the measurements pointed at. A warm t27c frontier went from about a minute to under a second, a bitstream that has not changed is found in a quarter of a second instead of four to nine, and the corpus suite that CI runs on every pull request takes half its old time. Thirteen pull requests, all merged; the record is the loop ledger, t27#8737.

Seconds before and after for six paths, on a log scale. Each pair is the conservative end of its measured range: the slowest "after" against the fastest "before". Measured on one 8-core Mac whose load varied from about 3 to about 140 overnight.

Where the time went

Almost none of it went into work that was new. It went into recomputing what had not changed since the last run, and into doing independent pieces of work one after another. Every fix below is one of those two.

Where	Before	Now	What changed	PR
`t27c frontier`, warm	55-68 s	~0.9 s	The four generated-code hashes of a spec come from a cache keyed on the spec, every spec it imports, and the bytes of the t27c binary	t27#8741
`t27c frontier` after a rebuild of t27c	55-68 s	6.3 s	The cache is filled by 8 workers first; the decisions are then made in order, exactly as before	t27#8847
`frontier --watch`, idle	33% of a core	3%	Each look stats the files and reads nothing unless a stat moved	t27#8825
`frontier --watch`, a save to a spec 16 others import	34.5 s	13.9 s	The reruns go side by side; specs that share a file name stay on one worker	t27#8856
`t27c silicon`, design unchanged	4.3-8.9 s	0.22-0.39 s	Tool digests (the 333 MB chipdb among them) come from a cache keyed on the file stat; the Python packages are read from the venv instead of `pip freeze`	t27#8808, t27#8814
A board run after `/bench approve`	build first, 30-550 s	load only	The bench agent builds the bitstream while the job waits for approval, without touching the cable	t27#8797
`t27c suite --corpus-only`	394-498 s	167-185 s	About 13,000 per-spec runs go 8 at a time; results are folded in file order	t27#8837, t27#8840, t27#8845
The same suite step in CI	221-257 s	108-140 s	Same change, measured on the runners	t27#8837

Three rules did most of the work

Key a cache on everything that can change the output, and on nothing else. The generated code of a spec depends on its imports, because constants are inlined across them, so the key holds the whole import closure. It also holds the binary itself: any rebuild of t27c is a new generator. A key that names too little serves wrong answers; a key that names too much, like a commit of an unrelated checkout, throws good answers away.
Check something cheap before something expensive. A file stat costs microseconds; reading and hashing 333 MB costs seconds. The watch and the digest cache both look at the stat first and read only what moved, and they take the stat before reading, so an edit that lands during a read is seen next time.
Run independent work side by side, and prove it changed nothing. Every parallel phase folds its results in input order, and each one was run both ways, with T27_SUITE_JOBS=1 and with the default: the error output was byte-identical, the JSON summaries equal apart from their timing fields, 259 failures both times.

Defects found on the way

The bitstream cache key held pip freeze, which named the editable prjxray package by the commit of the t27 checkout around it. A commit there would have orphaned every cached bitstream, while an edit to prjxray itself never reached the key (t27#8814).
When the bench agent stopped a build that ran past its hour, yosys and nextpnr kept running under launchd. Its timeout now stops the whole process tree (t27#8819).
The first version of the watch spent a third of a core doing nothing (t27#8825).
The new tri hot read its first silicon measurement as OVER, 28 s on a healthy cache: every tenth reuse hit is rebuilt from scratch on purpose, as an audit of the key, and that run had been timed. It now times such a run once more (t27#8872).

Where the time still goes

Path	Now	Where it goes	Next step
Edit a spec, get its verdict	~2 s per spec	Zig compiles and relinks the test binary on every run; t27c itself takes 0.03 s	Skip the relink: about 0.2-0.3 s per spec. It changes the test runner that every seal names, so it needs one full re-mint
Change logic, get a bitstream	36.7 s (ternary_link)	nextpnr 27.3 s: clock routing searches the whole chip for the BSCAN to BUFG arc, and the router sets up every wire of the 200T before routing a few thousand	A patch with byte-identical output makes clock routing 1.8-5x faster (t27#8754); a place-and-route process that stays resident would remove the setup
Bitstream onto the board	~13-15 s	9.73 MB over JTAG at the default clock	A faster JTAG clock on the HS2 cable, about 3 s; needs a test on the board
Approval to the start of a run	up to 60 s	The bench agent polls once a minute	Poll every 15 s, at about 180 more GitHub API calls an hour
`t27c suite`	~170 s	The C-header gate: 72 s of `cc -fsyntax-only` on every spec, every run	Cache its results by content (t27#8900)

Each next step in this table changes something outside the loop: what every seal records, what the board is sent, the GitHub API budget, or a file the project only lets its owner open for hand-written code. None of them was taken without the owner.

Check it yourself

tri hot runs each hot path once to warm it, then once timed, and says OVER when one is past its budget, or ran and failed. It is the regression test for the caches above, and the loop now starts every tick with it.

$ T27_OPENXC7=$HOME/t27/build/fpga/openxc7 tri hot
OK       frontier, warm: 856 ms (budget 5000 ms)
OK       silicon, reuse hit: 242 ms (budget 2000 ms)

What this does not settle

No board run was made after these changes: the ~13-15 s board load is from earlier runs, and the faster JTAG clock is untested.
All timings come from one Mac whose load varied from about 3 to about 140; the pairs were taken under the same load, but an idle-machine run of the whole flow is still owed.
The nextpnr patch is measured on two designs only (byte-identical output on both); it is not upstream and not in the toolchain the bench uses.
Skipping the per-run zig relink would cut a verdict to about 0.2-0.3 s, but it changes the test runner every seal names; the cost of the re-mint it forces is estimated, not measured.
