Phi as a ratio
You will learn
How phi_ratio.t27 computes a split for any width, and why the distance from 1 / phi does not shrink at every step.
phi_ratio.t27 sets PHI_RATIO_TARGET to 1 / phi, about 0.618, and its function phi_split works for any width: of the N - 1 bits after the sign, round((N - 1) / phi^2) go to the exponent and the rest to the mantissa. Its table verify_phi_split holds seven widths, and all seven match the family: GF4 splits 1 and 2, GF8 3 and 4, GF12 4 and 7, GF16 6 and 9, GF20 7 and 12, GF24 9 and 14, GF32 12 and 19. The distance from 1 / phi does not fall at every step: GF8 at 0.132 is further than GF4 at 0.118, and GF16 at 0.049 is further than GF12 at 0.047.
Try it
Run the tests of phi_ratio.t27 and find the one that checks GF16 at 6 and 9. Then compute 3 / 4 and 4 / 7 against 0.618 and say which is further.
Seven widths split by one rule, and how far each sits from 1 / phi, read from phi_ratio.t27. Lesson 2 of the GoldenFloat course.
specs/numeric/phi_ratio.t27
// SPDX-License-Identifier: Apache-2.0
// t27/specs/numeric/phi_ratio.t27
// φ-Ratio Proof — Derivation of GoldenFloat exp/mantissa split
// NUMERIC-STANDARD-001 — Agent 9 (P0)
module PhiRatio {
// Import sacred constants
use math::constants;
use math::sacred_physics;
// ═════════════════════════════════════════════════════════════════
// 1. Golden Ratio Target for Float Formats
// ═════════════════════════════════════════════════════════════════════════
// The ideal exp/mantissa ratio for floating point formats
// Derived from sacred physics: 1/φ ≈ 0.618
const PHI_RATIO_TARGET : f64 = sacred_physics::PHI_INV; // 0.618...
// φ² = φ + 1 (golden ratio identity)
// This gives us: 1/φ = φ - 1 ≈ 0.618
const PHI_SQ : f64 = sacred_physics::PHI * sacred_physics::PHI;
// ═════════════════════════════════════════════════════════════════
// 2. φ-Split Formula — Derive optimal exp/mantissa bits
// ═════════════════════════════════════════════════════════════════════════
// For a floating point format with N bits total (including sign):
// bits = sign + exp + mant
// sign = 1 (always)
// available = N - 1 = exp + mant
//
// The φ-principle states: exp/mant = 1/φ
// exp = (available) / (φ + 1)
// mant = available - exp
//
// Since φ + 1 = φ², we have:
// exp = (N - 1) / φ²
// mant = N - 1 - exp
struct PhiSplitResult {
exp_bits : u8,
mant_bits : u8,
ratio : f64,
phi_dist : f64,
}
fn phi_split(bits: u8) -> PhiSplitResult {
const available = bits - 1; // Exclude sign bit
const phi_sq = sacred_physics::PHI * sacred_physics::PHI;
// exp = round((N-1) / φ²)
const exp_raw = (available as f64) / phi_sq;
const exp_bits = round(exp_raw) as u8;
// mant = N - 1 - exp
const mant_bits = available - exp_bits;
const ratio = (exp_bits as f64) / (mant_bits as f64);
const phi_dist = abs(ratio - PHI_RATIO_TARGET);
return PhiSplitResult{
exp_bits = exp_bits,
mant_bits = mant_bits,
ratio = ratio,
phi_dist = phi_dist,
};
}
// ═════════════════════════════════════════════════════════════════
// 3. Verify GoldenFloat Family against φ-Split
// ═════════════════════════════════════════════════════════════════════════
struct FormatComparison {
name : string,
bits : u8,
actual_exp : u8,
actual_mant : u8,
phi_split_exp : u8,
phi_split_mant : u8,
matches_phi_split : bool,
tradeoff_note : string,
}
fn verify_phi_split() -> [7]FormatComparison {
return [
// GF4: φ-split gives exp=1, mant=2 → MATCH
FormatComparison{
name = "GF4",
bits = 4,
actual_exp = 1,
actual_mant = 2,
phi_split_exp = 1,
phi_split_mant = 2,
matches_phi_split = true,
tradeoff_note = "Perfect φ-split match",
},
// GF8: φ-split gives exp=3, mant=4 → MATCH
FormatComparison{
name = "GF8",
bits = 8,
actual_exp = 3,
actual_mant = 4,
phi_split_exp = 3,
phi_split_mant = 4,
matches_phi_split = true,
tradeoff_note = "Exact match: round(7/φ²)=3",
},
// GF12: φ-split gives exp=4, mant=7 → MATCH
FormatComparison{
name = "GF12",
bits = 12,
actual_exp = 4,
actual_mant = 7,
phi_split_exp = 4,
phi_split_mant = 7,
matches_phi_split = true,
tradeoff_note = "Exact match: round(11/φ²)=4",
},
// GF16: φ-split gives exp=6, mant=9 → MATCH
FormatComparison{
name = "GF16",
bits = 16,
actual_exp = 6,
actual_mant = 9,
phi_split_exp = 6,
phi_split_mant = 9,
matches_phi_split = true,
tradeoff_note = "PRIMARY FORMAT: exact match: round(15/φ²)=6",
},
// GF20: φ-split gives exp=7, mant=12 → MATCH
FormatComparison{
name = "GF20",
bits = 20,
actual_exp = 7,
actual_mant = 12,
phi_split_exp = 7,
phi_split_mant = 12,
matches_phi_split = true,
tradeoff_note = "Exact match: round(19/φ²)=7",
},
// GF24: φ-split gives exp=9, mant=14 → MATCH
// (This row said 6/17 and "no match"; phi_split(24) is 9/14, see
// invariant phi_split_gf24_matches_round below.)
FormatComparison{
name = "GF24",
bits = 24,
actual_exp = 9,
actual_mant = 14,
phi_split_exp = 9,
phi_split_mant = 14,
matches_phi_split = true,
tradeoff_note = "Exact match: round(23/φ²)=9",
},
// GF32: φ-split gives exp=12, mant=19 → MATCH
// (This row said 8/23 and "no match"; phi_split(32) is 12/19.)
FormatComparison{
name = "GF32",
bits = 32,
actual_exp = 12,
actual_mant = 19,
phi_split_exp = 12,
phi_split_mant = 19,
matches_phi_split = true,
tradeoff_note = "Exact match: round(31/φ²)=12",
},
];
}
// ═════════════════════════════════════════════════════════════════
// 4. Theoretical Proofs
// ═════════════════════════════════════════════════════════════════════════
// Proof that φ-split minimizes information loss
// for a given bit budget under scale-invariant assumptions.
fn golden_self_similarity_proof() -> string {
// The golden ratio φ is defined by identity: φ² = φ + 1
// Dividing both sides by φ² gives: 1 = 1/φ + 1/φ²
//
// Self-similarity constraint for bit allocation:
// The ratio e/m should equal ratio m/(e+m)
// This means: e/m = 1/(e/m + 1)
//
// Let r = e/m. Then: r = 1/(r + 1)
// Solving: r² + r - 1 = 0
// r = (√5 - 1)/2 = 1/φ ≈ 0.618
//
// This is NOT an optimization problem (maximizing e×m gives r=1 by AM-GM).
// It is a self-similarity constraint — a defining property of φ.
return "φ is unique self-similar proportion: e/m = m/(e+m) → r = 1/φ";
}
// Theorem 2: Optimal Rounding
// The function round((N-1)/φ²) gives integer closest to φ-proportion.
fn optimal_rounding_proof() -> string {
// For integer bit allocation, we must choose between floor and ceil.
// The φ-proportion gives exp_ideal = (N-1)/φ² (real number), and
// round() picks the integer nearest to it.
//
// (This used to claim that 1/φ MAXIMIZES dynamic_range * precision.
// It does not: maximizing e*m gives r = 1 by AM-GM, as the proof
// above says. 1/φ is a self-similarity constraint, not an optimum.)
return "exp = round((N-1)/φ²) is the integer nearest the φ-proportion exp/mant = 1/φ";
}
// ═════════════════════════════════════════════════════════════════
// 5. Connection to Sacred Physics
// ═════════════════════════════════════════════════════════════════════════
// The φ-ratio appears throughout sacred physics:
// - Consciousness threshold C = φ⁻¹
// - Specious present t = φ⁻² seconds
// - Neural gamma band f_γ = φ³ * π / γ
//
// GoldenFloat formats inherit this sacred proportion.
fn sacred_connection() -> string {
// Shared VALUE only: sacred_physics::C_THRESHOLD is defined as PHI_INV.
// No physical link is claimed here [Open conjecture].
return "GoldenFloat exp/mant target = sacred_physics::PHI_INV, the same value as sacred_physics::C_THRESHOLD";
}
// ═════════════════════════════════════════════════════════════════
// 6. Utility functions
// ═════════════════════════════════════════════════════════════════════════
fn compute_phi_distance(exp_bits: u8, mant_bits: u8) -> f64 {
const ratio = (exp_bits as f64) / (mant_bits as f64);
return abs(ratio - PHI_RATIO_TARGET);
}
fn is_phi_optimal(exp_bits: u8, mant_bits: u8, tolerance: f64) -> bool {
return compute_phi_distance(exp_bits, mant_bits) < tolerance;
}
fn recommend_format(total_bits: u8) -> PhiSplitResult {
return phi_split(total_bits);
}
// ═════════════════════════════════════════════════════════════════
// 7. Round function (stub)
// ═════════════════════════════════════════════════════════════════════════
fn round(x: f64) -> f64 {
// Round to nearest integer (round half away from zero)
if (x < 0.0) {
let xi = x as i64;
let frac = x - (xi as f64);
if (frac <= -0.5) {
return (xi - 1) as f64;
}
return xi as f64;
}
let xi = x as i64;
let frac = x - (xi as f64);
if (frac >= 0.5) {
return (xi + 1) as f64;
}
return xi as f64;
}
fn abs(x: f64) -> f64 {
if (x < 0.0) {
return -x;
}
return x;
}
fn pow(base: f64, exp: f64) -> f64 {
// Power function with binary exponentiation for integer exponents
// and logarithm approximation for fractional exponents
if (base <= 0.0) {
if (exp == 0.0) {
return 1.0; // 0^0 defined as 1 in this context
}
if (base == 0.0 && exp > 0.0) {
return 0.0;
}
if (base < 0.0 && exp == floor(exp)) {
// Negative base with integer exponent: handle via absolute value
let exp_int = exp as i64;
let result = pow(-base, exp);
if (exp_int % 2 == 0) {
return result;
}
return -result;
}
return 0.0 / 0.0; // NaN for negative base with non-integer exp
}
// Handle n = 0
if (exp == 0.0) {
return 1.0;
}
// Check if exponent is an integer
let is_integer = exp == floor(exp);
if is_integer {
// Integer exponent: use binary exponentiation
let exp_int = exp as i64;
let mut result = 1.0;
let mut base_acc = base;
let mut e = exp_int;
if e < 0 {
e = -e;
base_acc = 1.0 / base_acc;
}
while e > 0 {
if e % 2 == 1 {
result = result * base_acc;
}
base_acc = base_acc * base_acc;
e = e / 2;
}
return result;
}
// Fractional exponent: x^y = exp(y * ln(x))
let ln_x = ln_approx(base);
let result = exp_approx(exp * ln_x);
return result;
}
// Natural logarithm approximation
fn ln_approx(x: f64) -> f64 {
if x <= 0.0 {
return 0.0 / 0.0; // NaN for non-positive
}
if x == 1.0 {
return 0.0;
}
// Use series: ln(x) = 2 * ((x-1)/(x+1) + 1/3*((x-1)/(x+1))^3 + ...)
// Sixty terms, not four: four left ln(4) off by about 3e-3, so
// pow(4.0, 0.5) missed 2.0 by far more than the 1e-6 its test asks.
let t = (x - 1.0) / (x + 1.0);
let t2 = t * t;
let mut power = t;
let mut sum = 0.0;
let mut k = 0;
while k < 60 {
sum = sum + power / ((2 * k + 1) as f64);
power = power * t2;
k = k + 1;
}
return 2.0 * sum;
}
// Exponential approximation
fn exp_approx(x: f64) -> f64 {
if x == 0.0 {
return 1.0;
}
// Use Taylor series: e^x = 1 + x + x^2/2! + x^3/3! + ...
let mut result = 1.0;
let mut term = 1.0;
let mut n = 1;
// For better range, use x/2^k approach
let mut exp_x = x;
if x > 10.0 {
let k = floor(x / 10.0) as i64;
exp_x = x - (k as f64) * 10.0;
} else if x < -10.0 {
let k = floor(-x / 10.0) as i64;
exp_x = x + (k as f64) * 10.0;
}
// Taylor series (10 terms)
for i in 1..=10 {
term = term * exp_x / (i as f64);
result = result + term;
}
return result;
}
// Floor function
fn floor(x: f64) -> f64 {
let xi = x as i64;
if x >= 0.0 || x == xi as f64 {
return xi as f64;
}
return (xi - 1) as f64;
}
// ═══════════════════════════════════════════════════════════════════════════════════════════════════════
// TDD-Inside-Spec: Tests and Invariants for φ-Ratio
// ═══════════════════════════════════════════════════════════════════════════════════════════════════════
test phi_split_for_gf4_perfect_match
given bits = 4
when result = phi_split(bits)
// 1/2 against 1/φ: phi_dist = 0.118034 (GF8, 3/4, is wider: 0.131966).
// (This asserted phi_dist < 0.01, which no 4-bit split can meet.)
then result.exp_bits == 1 and result.mant_bits == 2 and result.phi_dist < 0.12
test phi_split_for_gf16_primary_format
given bits = 16
when result = phi_split(bits)
then result.exp_bits == 6 and result.mant_bits == 9 and result.phi_dist < 0.05
test phi_split_for_gf32_near_optimal
given bits = 32
when result = phi_split(bits)
then result.exp_bits == 12 and result.mant_bits == 19 and result.phi_dist < 0.02
test phi_split_sum_constraint
given bits = 16
when result = phi_split(bits)
then result.exp_bits + result.mant_bits == bits - 1
test phi_ratio_target_equals_phi_inverse
given target = PHI_RATIO_TARGET
when inverse = sacred_physics::PHI_INV
then abs(target - inverse) < 1e-15
test phi_split_ratio_approximates_phi_inverse
given bits = 16
when result = phi_split(bits)
and ratio = result.exp_bits as f64 / result.mant_bits as f64
then abs(ratio - PHI_RATIO_TARGET) < 0.05
test phi_optimality_proof_derivative
// phi_optimality_proof() never existed; the proof is this function.
given proof = golden_self_similarity_proof()
when contains_optimal = proof.contains("r = 1/φ")
then contains_optimal == true
test compute_phi_distance_for_gf16
given exp = 6
and mant = 9
// 6/9 = 0.6667 against 0.6180: distance 0.0486.
// (This said > 0.1 behind a `;` the parser dropped with the clause.)
when distance = compute_phi_distance(exp, mant)
then distance > 0.04 and distance < 0.05
test is_phi_optimal_tolerance_check
// GF16's real split. (It was 4/11, distance 0.254, which is NOT
// within 0.05; the test asserted the opposite.)
given exp = 6
and mant = 9
and tolerance = 0.05
when optimal = is_phi_optimal(exp, mant, tolerance)
then optimal == true
test verify_phi_split_all_formats_compared
given comparisons = verify_phi_split()
when gf4_matches = comparisons[0].matches_phi_split
and gf16_primary = comparisons[3].tradeoff_note.contains("PRIMARY")
then gf4_matches == true and gf16_primary == true
test sacred_connection_phi_ratio_equals_threshold
given connection = sacred_connection()
when has_threshold = connection.contains("C_THRESHOLD")
and has_phi_inverse = connection.contains("PHI_INV")
then has_threshold == true and has_phi_inverse == true
test phi_ratio_round_positive
given result = round(3.7)
then result == 4.0
test phi_ratio_round_negative
given result = round(-3.7)
then result == -4.0
test phi_ratio_round_half_up
given result = round(3.5)
then result == 4.0
test phi_ratio_round_half_down
given result = round(-3.5)
then result == -4.0
test phi_ratio_round_integer
given result = round(5.0)
then result == 5.0
test phi_ratio_round_zero
given result = round(0.0)
then result == 0.0
test phi_ratio_pow_zero_exponent_returns_one
given result = pow(2.0, 0.0)
then abs(result - 1.0) < 1e-15
test phi_ratio_pow_one_exponent_returns_base
given result = pow(5.0, 1.0)
then abs(result - 5.0) < 1e-15
test phi_ratio_pow_positive_integer_exponent
given result = pow(2.0, 10.0)
and expected = 1024.0
then abs(result - expected) < 1e-10
test phi_ratio_pow_negative_integer_exponent
given result = pow(2.0, -3.0)
and expected = 0.125
then abs(result - expected) < 1e-10
test phi_ratio_pow_fractional_exponent
given result = pow(4.0, 0.5)
and expected = 2.0
then abs(result - expected) < 1e-6
test phi_ratio_pow_phi_squared
given result = pow(sacred_physics::PHI, 2.0)
and expected = sacred_physics::PHI * sacred_physics::PHI
then abs(result - expected) < 1e-10
test phi_ratio_pow_zero_base_positive_exponent
given result = pow(0.0, 5.0)
then result == 0.0
test phi_ratio_pow_one_base_any_exponent
given result1 = pow(1.0, 10.0)
and result2 = pow(1.0, -5.0)
then abs(result1 - 1.0) < 1e-15 and abs(result2 - 1.0) < 1e-15
test phi_ratio_ln_approx_of_one
given result = ln_approx(1.0)
then abs(result) < 1e-15
test phi_ratio_ln_approx_of_e
given e = 2.718281828459045
and result = ln_approx(e)
then abs(result - 1.0) < 0.01
test phi_ratio_ln_approx_negative_returns_nan
given result = ln_approx(-1.0)
then result != result // NaN check
test phi_ratio_exp_approx_zero
given result = exp_approx(0.0)
then abs(result - 1.0) < 1e-15
test phi_ratio_exp_approx_one
given e = 2.718281828459045
and result = exp_approx(1.0)
then abs(result - e) < 0.01
test phi_ratio_exp_approx_negative
given result = exp_approx(-1.0)
and expected = 1.0 / 2.718281828459045
then abs(result - expected) < 0.01
test phi_ratio_floor_positive
given result = floor(3.7)
then result == 3.0
test phi_ratio_floor_negative
given result = floor(-3.2)
then result == -4.0
test phi_ratio_floor_integer
given result = floor(5.0)
then result == 5.0
test phi_ratio_floor_zero
given result = floor(0.0)
then result == 0.0
invariant phi_round_returns_integer
// For every x; checked at three, each lands on a whole number.
assert round(3.7) == floor(round(3.7)) and round(-3.7) == floor(round(-3.7))
and round(0.2) == floor(round(0.2))
invariant phi_round_half_away_from_zero
assert round(2.5) == 3.0 and round(-2.5) == -3.0
invariant phi_round_symmetric
// For every x >= 0; checked at three, including a half.
assert round(-0.4) == -round(0.4) and round(-2.5) == -round(2.5)
and round(-7.6) == -round(7.6)
invariant phi_pow_zero_exponent_identity
// For every positive x; checked at three points, one on each side of 1.
given x1 = 0.5
and x2 = 2.5
and x3 = 7.0
assert abs(pow(x1, 0.0) - 1.0) < 1e-15 and abs(pow(x2, 0.0) - 1.0) < 1e-15
and abs(pow(x3, 0.0) - 1.0) < 1e-15
invariant phi_pow_one_exponent_identity
// For every valid x; checked at three points.
given x1 = 0.5
and x2 = 2.5
and x3 = 7.0
assert abs(pow(x1, 1.0) - x1) < 1e-15 and abs(pow(x2, 1.0) - x2) < 1e-15
and abs(pow(x3, 1.0) - x3) < 1e-15
invariant phi_pow_multiply_exponents
given a = 2.0
and b = 3.0
assert abs(pow(pow(a, 2.0), b) - pow(a, 6.0)) < 1e-10
invariant phi_ln_exp_inversion
given x = 2.0
and y = ln_approx(x)
then abs(exp_approx(y) - x) < 0.01
invariant phi_exp_ln_inversion
given x = 1.5
and y = exp_approx(x)
then abs(ln_approx(y) - x) < 0.01
invariant phi_floor_returns_integer
// For every x; checked at three, each lands on a whole number.
assert floor(3.7) == 3.0 and floor(-3.2) == -4.0 and floor(0.0) == 0.0
invariant phi_floor_monotonic
given x1 = 2.5
and x2 = 3.5
assert floor(x1) <= floor(x2)
invariant phi_floor_zero_or_less
// For every x; checked at three, on both sides of zero.
assert floor(3.7) <= 3.7 and floor(-3.2) <= -3.2 and floor(5.0) <= 5.0
invariant phi_split_sum_equals_available_bits
// For every width; checked at three.
assert phi_split(8).exp_bits + phi_split(8).mant_bits == 7
and phi_split(16).exp_bits + phi_split(16).mant_bits == 15
and phi_split(32).exp_bits + phi_split(32).mant_bits == 31
invariant phi_ratio_target_is_phi_inverse
assert PHI_RATIO_TARGET == sacred_physics::PHI_INV
invariant phi_distance_non_negative
// For every split; checked below, at and above the target.
assert compute_phi_distance(1, 2) >= 0.0 and compute_phi_distance(6, 9) >= 0.0
and compute_phi_distance(9, 1) >= 0.0
invariant phi_optimal_proof_valid
assert golden_self_similarity_proof().contains("1/φ")
invariant gf4_format_is_phi_optimal
// GF4 is the coarsest rung: 1/2 against 1/φ, distance 0.118034.
// (This asserted < 0.01; four bits cannot get closer than 0.118.)
assert phi_split(4).phi_dist < 0.12
invariant exp_bits_less_than_total
// For every width; checked at three.
assert phi_split(8).exp_bits < 8 and phi_split(16).exp_bits < 16 and phi_split(32).exp_bits < 32
invariant mant_bits_less_than_total
// For every width; checked at three.
assert phi_split(8).mant_bits < 8 and phi_split(16).mant_bits < 16 and phi_split(32).mant_bits < 32
invariant phi_split_round_matches_all_formats
// CRITICAL: Verify that round((N-1)/φ²) matches ALL GF formats exactly
assert phi_split(4).exp_bits == 1 // GF4: round(3/φ²) = round(1.146) = 1
invariant phi_split_gf8_matches_round
assert phi_split(8).exp_bits == 3 // GF8: round(7/φ²) = round(2.674) = 3
invariant phi_split_gf12_matches_round
assert phi_split(12).exp_bits == 4 // GF12: round(11/φ²) = round(4.202) = 4
invariant phi_split_gf16_matches_round
assert phi_split(16).exp_bits == 6 // GF16: round(15/φ²) = round(5.729) = 6
invariant phi_split_gf20_matches_round
assert phi_split(20).exp_bits == 7 // GF20: round(19/φ²) = round(7.257) = 7
invariant phi_split_gf24_matches_round
assert phi_split(24).exp_bits == 9 // GF24: round(23/φ²) = round(8.785) = 9
invariant phi_split_gf32_matches_round
assert phi_split(32).exp_bits == 12 // GF32: round(31/φ²) = round(11.841) = 12
invariant phi_distance_bound_by_zero
assert compute_phi_distance(0, 1) == abs(0.0 - PHI_RATIO_TARGET)
bench phi_split_computation_time
measure: nanoseconds to compute phi_split(32)
target: < 100ns
bench verify_phi_split_computation_time
measure: nanoseconds to verify all 7 formats
target: < 500ns
bench compute_phi_distance_throughput
measure: phi_distance computations per second
target: > 1M computations/sec
// =====================================================================
// Phase A3 (epic #181) -- L5 Trinity runtime invariant blocks (appended)
// phi^2 + phi^-2 = 3 is the ONLY [Verified] phi-fact. f64 tol 1e-14.
// =====================================================================
test test_l5_phi_sq_equals_phi_plus_one
// [Verified] phi^2 = phi + 1 -- defining algebraic identity of phi.
// L5 canonical. f64 check, tolerance 1e-14.
given phi = sacred_physics::PHI
and phi_sq = PHI_SQ
when diff = abs(phi_sq - (phi + 1.0))
then diff < 1e-14
test test_l5_phi_sq_plus_phi_inv_sq_equals_3
// [Verified] phi^2 + phi^-2 = 3 -- the ONLY [Verified] phi-fact (L5).
// Algebraic proof: phi^2 = phi+1, phi^-2 = 2-phi, sum = 3.
// f64 check, tolerance 1e-14. 50-digit audit lives in pellis_verify.t27.
given phi = sacred_physics::PHI
and phi_sq = PHI_SQ
and phi_inv = 1.0 / phi
and phi_inv2 = phi_inv * phi_inv
when lhs = phi_sq + phi_inv2
and diff = abs(lhs - 3.0)
then diff < 1e-14
test test_l5_phi_inv2_equals_2_minus_phi
// Verify the algebraic sub-fact: phi^-2 = 2 - phi (used in the proof above).
// [Verified]. f64 check, tolerance 1e-14.
given phi = sacred_physics::PHI
and phi_sq = PHI_SQ
and phi_inv2 = 1.0 / phi_sq
when diff = abs(phi_inv2 - (2.0 - phi))
then diff < 1e-14
// -----------------------------------------------------------------------
// Invariants
// -----------------------------------------------------------------------
invariant l5_phi_sq_equals_phi_plus_one
// [Verified] L5 law: phi^2 = phi + 1.
// Tolerance 1e-14 (f64; 50-digit audit lives in pellis_verify.t27).
// This invariant is a RUNTIME GUARD, not the high-precision audit.
assert abs(PHI_SQ - (sacred_physics::PHI + 1.0)) < 1e-14
invariant l5_phi_sq_plus_phi_inv_sq_equals_3
// [Verified] L5 law: phi^2 + phi^-2 = 3.
// The ONLY [Verified] phi-fact in this codebase (GOLDEN CHAIN Law L5).
// All other phi claims are [Open conjecture] with a falsification path.
// Tolerance 1e-14 (f64 runtime guard).
// 50-digit arbitrary-precision checking belongs to the pellis audit path.
assert abs(PHI_SQ + (1.0 / PHI_SQ) - 3.0) < 1e-14
// -----------------------------------------------------------------------
// Benchmark
// -----------------------------------------------------------------------
bench bench_l5_phi_identity_check
// Measure cost of evaluating both L5 identities in sequence.
// Expected: < 50ns (pure floating-point arithmetic, no allocations).
given phi = sacred_physics::PHI
and phi_sq = PHI_SQ
when _a = abs(phi_sq - (phi + 1.0))
and _b = abs(phi_sq + (1.0 / phi_sq) - 3.0)
then elapsed_time_ns < 50
}
All lessons
Module 1 · The rule and its numbers
One rule splits every width, the ratio it aims at, and the Lucas numbers behind the 3.
Module 2 · Why phi, why three
Why the split is phi, why base three, and how a spec checks GF16 keeps phi.
Module 3 · The small rungs: GF4 to GF8
GF4, GF6 and GF8, the fewest bits, where rounding to whole bits costs the most.
Module 4 · Ten to fourteen bits
GF10, GF12 and GF14, and how the distance from 1 / phi moves as the word grows.
Module 5 · GF16 at work
The primary 16-bit format, a two-term dot product in GF-T16, then GF20 and GF24.
Module 6 · GF32 to GF64
GF32 beside IEEE single, GF48 with no IEEE twin, GF64 beside IEEE double.
Module 7 · GF96 to GF256
GF96, GF128 and GF256, where the specs hold the layout with invariants.
Module 8 · The widest rungs, then trits
GF512 and GF1024, the two widest rungs, then GF-T8, where the exponent moves to trits.
Module 9 · More trits, then the decode
GF-T16 and GF-T32, then why fixed fields decode in parallel and a posit does not.
