GF4: four bits
You will learn
The smallest GoldenFloat: one sign bit, one exponent bit, two mantissa bits, bias 0.
GF4 has 4 bits: 1 sign, 1 exponent, 2 mantissa, and its exponent bias is 0. With one exponent bit there are only two scales, 1 and 2, so its 16 codes are coarse. The rule gives E = round(3 / phi^2) = 1, and the ratio E / M is 0.5, a distance of 0.118 from 1 / phi. The AI numbers course opens the same spec for another reason; here it is the lowest rung of the family.
Try it
Find EXP_BIAS and PHI_DISTANCE in gf4.t27, then the invariant that bounds the distance. Open the decode function and find the two scales one exponent bit gives.
GF4: 4 bits as the spec lays them out, read from gf4.t27. Lesson 7 of the GoldenFloat course.
specs/numeric/gf4.t27
// SPDX-License-Identifier: Apache-2.0
// t27/specs/numeric/gf4.t27
// GoldenFloat4 — 4-bit φ-structured floating point
// NUMERIC-STANDARD-001 — Agent 2 (P1)
module GF4 {
// Import base format family
use numeric::goldenfloat_family;
use numeric::phi_ratio;
// ═════════════════════════════════════════════════════════════════
// 1. Format Definition
// ═════════════════════════════════════════════════════════════════════════
// GF4 bit layout: [S|E|MM]
// S: 1 bit (sign)
// E: 1 bit (exponent)
// M: 2 bits (mantissa)
const BITS : u8 = 4;
const SIGN_BITS : u8 = 1;
const EXP_BITS : u8 = 1;
const MANT_BITS : u8 = 2;
// Bias for exponent (0-biased for GF4)
const EXP_BIAS : u8 = 0;
// φ-ratio: exp/mant = 1/2 = 0.5 (phi_distance = 0.118)
const PHI_DISTANCE : f64 = 0.1180339887498949;
// ═════════════════════════════════════════════════════════════════
// 2. GoldenFloat4 Type
// ═════════════════════════════════════════════════════════════════════════
struct GF4 {
raw : u4, // 4-bit raw value
}
// ═════════════════════════════════════════════════════════════════
// 3. Encoding/Decoding
// ═════════════════════════════════════════════════════════════════════════
// Encode f32 to GF4
fn encode(value: f32) -> GF4 {
// Special cases
if (value == 0.0) {
return GF4{ raw = 0b0000 };
}
if (value < 0.0) {
const pos = encode(-value).raw;
return GF4{ raw = pos | 0b1000 }; // Set sign bit
}
// For GF4, quantize to available values
// Available positive values (mant * exp_scale):
// mant=0.00, exp=1.0 → 0.00
// mant=0.25, exp=1.0 → 0.25
// mant=0.50, exp=1.0 → 0.50
// mant=0.75, exp=1.0 → 0.75
// mant=0.00, exp=2.0 → 0.00
// mant=0.25, exp=2.0 → 0.50
// mant=0.50, exp=2.0 → 1.00
// mant=0.75, exp=2.0 → 1.50
// Unique positive non-zero values: 0.25, 0.5, 0.75, 1.0, 1.5
if (value <= 0.375) {
// 0.25
return GF4{ raw = 0b0001 };
} else if (value <= 0.625) {
// 0.5
return GF4{ raw = 0b0010 };
} else if (value <= 0.875) {
// 0.75
return GF4{ raw = 0b0011 };
} else if (value <= 1.25) {
// 1.0
return GF4{ raw = 0b0101 };
} else {
// 1.5 (max)
return GF4{ raw = 0b0111 };
}
}
// Decode GF4 to f32
fn decode(gf: GF4) -> f32 {
const sign_bit = (gf.raw & 0b1000) != 0;
const exp_bit = (gf.raw & 0b0100) != 0;
const mant_bits = gf.raw & 0b0011;
// Zero
if (gf.raw == 0) {
return 0.0;
}
// Decode mantissa (2 bits → values 0, 0.25, 0.5, 0.75)
const mant = (mant_bits as f32) / 4.0;
// Decode exponent (1 bit → 1.0 or 2.0)
const exp_scale = if (exp_bit) { 2.0 } else { 1.0 };
const value = mant * exp_scale;
if (sign_bit) {
return -value;
}
return value;
}
// ═════════════════════════════════════════════════════════════════
// 4. Format Properties
// ═════════════════════════════════════════════════════════════════════════
fn max_value() -> f32 {
// Max: mant=0.75, exp=2.0 → 1.5
return 1.5;
}
fn min_positive() -> f32 {
// Min positive: mant=0.25, exp=1.0 → 0.25
return 0.25;
}
fn epsilon() -> f32 {
// Smallest representable difference at 1.0
return 0.25;
}
// ═════════════════════════════════════════════════════════════════
// 5. Validation
// ═════════════════════════════════════════════════════════════════════════
fn validate_format() -> bool {
// Check that we match the goldenfloat_family definition
const fmt = goldenfloat_family::get_format_by_name("GF4");
return (fmt != null) &&
(fmt.?.bits == BITS) &&
(fmt.?.exp_bits == EXP_BITS) &&
(fmt.?.mant_bits == MANT_BITS);
}
// ═════════════════════════════════════════════════════════════════
// 6. Use Cases
// ═════════════════════════════════════════════════════════════════════════
// GF4 is optimal for:
// - Extreme compression (87.5% smaller than FP32)
// - Binary/ternary classification
// - Attention masks
// - Activation sparsity indicators
// Memory: 4 bits = 0.5 bytes (8x FP32 in same space)
const MEMORY_RATIO_VS_FP32 : f32 = 4.0 / 32.0; // 0.125
// ═══════════════════════════════════════════════════════════════════════════════════════════════════════
// TDD-Inside-Spec: Tests and Invariants for GF4
// ═══════════════════════════════════════════════════════════════════════════════════════════════════════
test gf4_decode_zero
given gf = GF4{ raw = 0b0000 }
when value = decode(gf)
then value == 0.0
test gf4_decode_positive_max
given gf = GF4{ raw = 0b0111 }
when value = decode(gf)
then value == 1.5
test gf4_decode_negative
given gf = GF4{ raw = 0b1001 }
when value = decode(gf)
then value < 0.0
test gf4_encode_zero_roundtrip
given original = 0.0
and encoded = encode(original)
and decoded = decode(encoded)
then decoded == original
test gf4_encode_0_25
given original = 0.25
and encoded = encode(original)
and decoded = decode(encoded)
then abs(decoded - 0.25) < 0.01
test gf4_encode_0_5
given original = 0.5
and encoded = encode(original)
and decoded = decode(encoded)
then abs(decoded - 0.5) < 0.01
test gf4_encode_0_75
given original = 0.75
and encoded = encode(original)
and decoded = decode(encoded)
then abs(decoded - 0.75) < 0.01
test gf4_encode_1_0
given original = 1.0
and encoded = encode(original)
and decoded = decode(encoded)
then abs(decoded - 1.0) < 0.01
test gf4_encode_1_5
given original = 1.5
and encoded = encode(original)
and decoded = decode(encoded)
then abs(decoded - 1.5) < 0.01
test gf4_encode_negative_values
given original = -0.5
and encoded = encode(original)
and decoded = decode(encoded)
then decoded < 0.0 and abs(decoded - (-0.5)) < 0.01
test gf4_encode_clamps_to_max
given original = 10.0
and encoded = encode(original)
and decoded = decode(encoded)
then decoded <= 1.5
test gf4_encode_quantization_small
given original = 0.3
and encoded = encode(original)
and decoded = decode(encoded)
then abs(decoded - 0.25) < 0.01
test gf4_max_value_is_1_5
given max_val = max_value()
then max_val == 1.5
test gf4_min_positive_is_0_25
given min_pos = min_positive()
then min_pos == 0.25
test gf4_bits_sum_correct
given total = SIGN_BITS + EXP_BITS + MANT_BITS
then total == BITS
test gf4_exp_mant_ratio_matches_phi_split
given ratio = (EXP_BITS as f64) / (MANT_BITS as f64)
and expected = 0.5
then abs(ratio - expected) < 0.01
test gf4_memory_ratio_vs_fp32
given ratio = MEMORY_RATIO_VS_FP32
then ratio == 0.125
test gf4_validate_format_success
given valid = validate_format()
then valid == true
invariant gf4_bits_constant
assert BITS == 4
invariant gf4_sign_bits_is_one
assert SIGN_BITS == 1
invariant gf4_exp_bits_is_one
assert EXP_BITS == 1
invariant gf4_mant_bits_is_two
assert MANT_BITS == 2
invariant gf4_max_value_positive
assert max_value() > 0.0
invariant gf4_min_positive_greater_than_zero
assert min_positive() > 0.0
invariant gf4_epsilon_positive
assert epsilon() > 0.0
invariant gf4_max_ge_min_positive
assert max_value() >= min_positive()
invariant gf4_phi_distance_within_tolerance
assert PHI_DISTANCE < 0.12
invariant gf4_encode_decode_roundtrip
given encoded = encode(x) for x in {0.25, 0.5, 0.75, 1.0, 1.5}
when decoded = decode(encoded)
then abs(decoded - x) < 0.01
invariant gf4_encode_zero_returns_zero
assert encode(0.0).raw == 0b0000
invariant gf4_encode_positive_no_sign_bit
given result = encode(1.0)
when has_sign = (result.raw & 0b1000) != 0
then has_sign == false
invariant gf4_encode_negative_has_sign_bit
given result = encode(-1.0)
when has_sign = (result.raw & 0b1000) != 0
then has_sign == true
bench gf4_encode_latency
measure: nanoseconds to encode(1.0)
target: < 100ns
bench gf4_decode_latency
measure: nanoseconds to decode(GF4{raw = 0b0101})
target: < 50ns
}
