Multiply, then add

You will learn

What a multiply-accumulate does with two signed products, and how the swap from lesson 12 breaks it.

Try it

In the recording, find the test that expects 512 and the test the planted bug breaks; then in the spec frame change the XOR in smul to OR yourself and see whether the browser catches it.

specs/ternary/gft_signed_mac.t27

module GftSignedMac;
// #1764 + GF-T: a spec-first SIGNED GF-T16 MAC (y = a1*b1 + a2*b2) with
// round-to-nearest-even, bit-exact to the ideal oracle gft16_ref.py (with sign).
// This is the piece real NN inference needs -- negative weights/activations and
// cancellation in the accumulator.
//
// Signed GF-T16: [ sign(1) : offset(7) : mant(9) ] (17 bits, held in a u32),
// magnitude value = (1+mant/512)*2^(offset-40). Signed mul = sign XOR + RNE
// magnitude mul. Signed add = same-sign RNE add, or (different sign) subtract the
// smaller magnitude from the larger: align, subtract with G guard bits, left-
// normalize, round to nearest even; result takes the larger operand's sign, or is
// zero on exact cancellation.
// All intermediates non-negative small ints -> i32 (signed shift/compare/mul on
// positives == unsigned, bit-identical to the oracle).

// --- RNE magnitude multiply (matches gft_mul_rne) ---
fn magmul(a: i32, b: i32) -> i32 {
    var ao : i32 = a >> 9;
    var am : i32 = a & 511;
    var bo : i32 = b >> 9;
    var bm : i32 = b & 511;
    var prod : i32 = (512 + am) * (512 + bm);
    var carry : i32 = 0;
    if (prod >= 524288) { carry = 1; }
    var q : i32 = prod >> 9;
    var r : i32 = prod & 511;
    var half : i32 = 256;
    if (carry == 1) { q = prod >> 10; r = prod & 1023; half = 512; }
    var mant : i32 = q - 512;
    if (r > half) { mant = mant + 1; }
    if (r == half) { if ((q & 1) == 1) { mant = mant + 1; } }
    var s : i32 = ao + bo + carry;
    var off : i32 = 0;
    if (s >= 40) { var rr : i32 = s - 40; if (rr >= 80) { off = 80; } else { off = rr; } }
    if (mant >= 512) { mant = 0; off = off + 1; if (off >= 80) { off = 80; } }
    return (off << 9) | mant;
}

// --- RNE magnitude same-sign add (matches gft_add_rne) ---
fn magadd(a: i32, b: i32) -> i32 {
    var ao : i32 = a >> 9;
    var am : i32 = a & 511;
    var bo : i32 = b >> 9;
    var bm : i32 = b & 511;
    var ho : i32 = bo; var hm : i32 = bm; var lo : i32 = ao; var lm : i32 = am;
    if (ao >= bo) { ho = ao; hm = am; lo = bo; lm = bm; }
    var hs : i32 = 512 + hm;
    var ls : i32 = 512 + lm;
    var d : i32 = ho - lo;
    if (d > 11) { d = 11; }
    var losh : i32 = ls >> d;
    var rem : i32 = ls - (losh << d);
    var s : i32 = hs + losh;
    var off : i32 = ho;
    var mant : i32 = s - 512;
    if (s >= 1024) {
        var g : i32 = s & 1;
        var pre : i32 = s >> 1;
        mant = pre - 512;
        if (g == 1) { if (rem > 0) { mant = mant + 1; } else { if ((pre & 1) == 1) { mant = mant + 1; } } }
        off = ho + 1; if (off >= 80) { off = 80; }
    } else {
        var t : i32 = rem << 1;
        var hf : i32 = 1 << d;
        if (t > hf) { mant = mant + 1; }
        else { if (t == hf) { if ((s & 1) == 1) { mant = mant + 1; } } }
    }
    if (mant >= 512) { mant = 0; off = off + 1; if (off >= 80) { off = 80; } }
    return (off << 9) | mant;
}

// --- RNE magnitude subtract, hi >= lo. Returns 0 on exact cancellation. G=14 guard bits. ---
fn magsub(hi: i32, lo: i32) -> i32 {
    if (hi == lo) { return 0; }
    var ho : i32 = hi >> 9; var hm : i32 = hi & 511;
    var lo_o : i32 = lo >> 9; var lm : i32 = lo & 511;
    var d : i32 = ho - lo_o; var hs : i32 = (512 + hm) << 14;
    var la : i32 = 0; var sticky : i32 = 0;
    if (d >= 26) { la = 0; sticky = 1; }
    else { var ls : i32 = (512 + lm) << 14; la = ls >> d; if ((ls - (la << d)) > 0) { sticky = 1; } }
    var diff : i32 = hs - la; var off : i32 = ho;
    var cap : i32 = 12; if (off - 1 < cap) { cap = off - 1; } if (cap < 0) { cap = 0; }
    var sh : i32 = 0;
    if (diff != 0) {
        var t : i32 = diff;
        if (t < 65536) { if (sh + 8 <= cap) { t = t << 8; sh = sh + 8; } }
        if (t < 1048576) { if (sh + 4 <= cap) { t = t << 4; sh = sh + 4; } }
        if (t < 4194304) { if (sh + 2 <= cap) { t = t << 2; sh = sh + 2; } }
        if (t < 8388608) { if (sh + 1 <= cap) { t = t << 1; sh = sh + 1; } }
    }
    diff = diff << sh; off = off - sh;
    var q : i32 = diff >> 14; var rem : i32 = diff - (q << 14); var half : i32 = 8192; var mant : i32 = q - 512;
    if (rem > half) { mant = mant + 1; }
    else { if (rem == half) { if (sticky == 1) { mant = mant + 1; } else { if ((q & 1) == 1) { mant = mant + 1; } } } }
    if (mant >= 512) { mant = 0; off = off + 1; if (off >= 80) { off = 80; } }
    return (off << 9) | mant;
}

fn smul(a: u32, b: u32) -> u32 {
    var sa : i32 = (a >> 16) as i32;
    var sb : i32 = (b >> 16) as i32;
    var mag : i32 = magmul((a & 65535) as i32, (b & 65535) as i32);
    return (((sa ^ sb) << 16) | mag) as u32;
}

fn sadd(a: u32, b: u32) -> u32 {
    var sa : i32 = (a >> 16) as i32;
    var ma : i32 = (a & 65535) as i32;
    var sb : i32 = (b >> 16) as i32;
    var mb : i32 = (b & 65535) as i32;
    if (sa == sb) { return ((sa << 16) | magadd(ma, mb)) as u32; }
    // different signs: a top-level r==0 guard (NOT nested inside the ma>=mb
    // branch -- gen-verilog does not lower that as an early return, so it fell
    // through to (sign<<16)|0 = a wrong negative zero on exact cancellation).
    var bsign : i32 = sa;
    var r : i32 = magsub(ma, mb);
    if (ma < mb) { r = magsub(mb, ma); bsign = sb; }
    if (r == 0) { return 0; }
    return ((bsign << 16) | r) as u32;
}

// The signed MAC: y = a1*b1 + a2*b2.
fn on_comb(a1: u32, b1: u32, a2: u32, b2: u32) -> u32 {
    return sadd(smul(a1, b1), smul(a2, b2));
}

// +1.0 = offset 40 mant 0 sign 0 = 20480. -1.0 = sign 1 = 0x15000 = 86016.
// (+1)*(+1) + (-1)*(-1) = 1 + 1 = 2.0 (+) = offset 41 = 20992.
test pp { assert_eq(on_comb(20480, 20480, 86016, 86016), 20992); }
// (+1)*(+1) + (+1)*(-1) = 1 - 1 = 0.
test cancel { assert_eq(on_comb(20480, 20480, 20480, 86016), 0); }
endmodule
