Gigabit Ethernet on Artix-7 without a vendor toolchain

2026-08-09 · 12 min read

RGMII at gigabit through Yosys, nextpnr-xilinx and Project X-Ray with no vendor tools — the six blockers that had to be patched, the one still open, and what the workaround costs.

FPGAOpen sourceEthernetArtix-7openXC7

The frame, before anything else

What works: three ALINX AX7203 boards exchange frames of a custom protocol over gigabit RGMII, with no operating system at either end and no vendor licence anywhere in the flow, which runs natively on a laptop. Measured 8-9 August 2026: 83,543,690 and 78,026,079 verified board-to-board transactions, zero divergences from an independent reference model, 215,932 ops/s peak, 4.71 and 4.74 microsecond hardware round trips. Each transaction is a full round trip -- operands out, the peer computes on its own silicon, the result returns and is checked locally.

What does not: a node negotiates its link on roughly half of power-ups — 23 of 48, a 95% interval of about 34-62%, and independent of what the RTL does across four structurally different designs. Every hypothesis inside the FPGA has been eliminated by measurement. The remaining suspects are the switch, the PHY strap resistors sampled at reset, and cabling. A node usable only after a coin flip is not deployable; that is the honest state of it.

What is not mine: the flow itself. Yosys is YosysHQ. nextpnr is YosysHQ and David Shah — the framework paper is Shah, Hung, Wolf, Bazanski, Gisselquist and Milanović at FCCM 2019 (arXiv:1903.10407), and it covers Lattice iCE40 and ECP5; Xilinx 7-series came later through nextpnr-xilinx. Project X-Ray and the xc7 bitstream database are SymbiFlow/F4PGA. The Xilinx port and Artix-7 support are openXC7, funded by NLnet. I did not build this stack. I found six places where it broke on my design and sent six patches.

Why RGMII and not SerDes

openXC7 has funded work on gigabit transceivers, but that targets GTP/GTX — high-speed serial lanes, aimed at 10G. Different problem. RGMII is source-synchronous DDR over ordinary user I/O on general-purpose registers. Cheaper, closer to a typical dev board with a gigabit PHY, and therefore it stresses primitives rather than transceivers: ODDR/IDDR, clock buffers, clock management.

Board: ALINX AX7203, part xc7a200tfbg484-2. The 125 MHz RGMII receive clock arrives on an SRCC pin (B17) and reaches a BUFG. Toolchain: nextpnr-xilinx at stable-backports (f8e7643) plus the open patches below, Yosys 0.63, prjxray via the regymm/openxc7 image, on a macOS arm64 host.

Blocker 1 — the router gave up before trying half the options

Path search from an SRCC pin to a clock buffer stopped at 50,000 iterations. The chip database holds more than 75,000 valid paths. The cap was set below the size of the search space, so "unroutable" actually meant "unfinished". The fix is one constant.

The path existed in the chip database the whole time: 75,492 wires. The search gave up at 50,000. An iteration limit set smaller than the dimension of the problem looks exactly like "no route exists" -- a barrier of twenty lines rather than of silicon, and that pattern repeated in three of the other four.

Blockers 2-5 — four ways a build dies quietly

Blocker 6 — the one that is still open

The hardware IDDR block does not capture at all. Place-and-route succeeds, timing is met, the FASM is well-formed and the bitstream configures — the data simply never appears. Reported upstream as issue #114 with an A/B/A/B bitstream flip on one board: a raw-pin build reads in-band status 0xD (1000 Mb/s, full duplex) and counts frames, while the IDDR build sees none. #115 initialises all four IFF flops rather than only Q1/Q2, which closes part of the configuration problem but not this. The receive path therefore uses fabric DDR capture instead.

The diagnosis itself is still open. A pre-existing report, issue #65 from janrinze in March 2025, records that SAME_EDGE_PIPELINED is rejected outright — prjxray only encodes SAME and OPPOSITE for IFF.DDR_CLK_EDGE — so the input DDR path has been thin here for a while.

The instrument was wrong before the conclusion was

The first version of this report said "Q1 is dead, Q2 works". That was wrong, and the reason is worth more than the finding.

Liveness was detected with a sticky OR: seen <= seen | q. That cannot distinguish a toggling output from one stuck at 1 — both end up 0xF. Adding the complementary sticky zero, zero <= zero | ~q, changes the picture entirely: an output is only really capturing if it has been observed both high and low.

Emitted IFF.DDR_CLK_EDGEQ1Q2
SAME_EDGEever-1 0x0, ever-0 0xF -> stuck LOWever-1 0xF, ever-0 0x0 -> stuck HIGH
neither bit emittedstuck HIGHstuck HIGH
OPPOSITE_EDGEnever highnever high

Byte assembly confirms it: sampling early in a frame, where the Ethernet preamble 0x55 must appear, yields F0 under SAME_EDGE and FF with no edge bits — constant levels, never 0x55. So the corrected finding is simpler and worse than the first one: both outputs are inert in every edge mode tried, while the pin demonstrably carries gigabit traffic.

A one-sided detector cannot tell alive from stuck. If an instrument can only ever report one of its two possible answers, it is not measuring — and it will agree with you every time.

What the workaround costs: jitter, and a dependence on frame size

Moving capture into the fabric is what exposed an effect invisible with a hardware IDDR: link stability depends on frame size. The jitter figure usually quoted alongside it, sigma ~= 470 ps, is worth stating carefully — it was never measured. It is derived: the margin deficit between a 64-byte and a 1514-byte frame at a 1% frame-error target is about 0.64 sigma, the observed span is five 0.06 ns steps or roughly 300 ps, and equating the two gives sigma ~= 470 ps ~= 0.12 UI. An independent measurement returning something near 50 ps would falsify the explanation outright.

FrameSizeMinimum working skew step
ARPshort26
ICMP98 bytes30
Full MTU1514 bytes31 (the maximum)

Jitter accumulates along the frame, so the required timing margin grows monotonically with frame length in bits. A full MTU frame only comes up at the last available step — the margin is exhausted, which is one more reason power-on is unreliable.

Calibrate skew to the longest frame you will ever send. A link tuned on ARP will drop its first full frame, and it will look like a flaky network rather than a calibration error.

The margin law — and why "jitter accumulates" is the wrong mechanism

The rule above is right. The explanation I first gave for it was not, and the numbers say so clearly enough that it is worth writing down properly.

Setup. RGMII at 1000BASE-T runs a 125 MHz clock, double data rate, four bits per edge — one unit interval UI = 4 ns, and a frame of B bytes is captured in N = 2B sampling edges. Let each edge carry a phase error X_i, i.i.d., symmetric, with standard deviation sigma. The frame is received correctly exactly when every edge lands inside the margin: |X_i| < m for all i.

Theorem 1 (frame-length margin law). P(frame OK) = (1 - 2(1 - F(m)))^N. For a target frame-error rate eps, the required margin is m(N) = F^-1(1 - eps/(2N)); for Gaussian error, m(N) = sigma * Phi^-1(1 - eps/(2N)), which is asymptotically sigma * sqrt(2 ln(2N/eps)).

So the margin does grow monotonically with frame length — but as sqrt(log N), not as sqrt(N). This is an extreme-value effect over N independent draws, not accumulation. Nothing integrates: RGMII forwards the clock alongside the data, so each edge is sampled afresh and phase error has no memory from one edge to the next.

Corollary 1 (the random-walk model is refuted). If the receive clock were independent, phase error would integrate as sigma_N = sigma * sqrt(N). At sigma = 470 ps and MTU (N = 3028), that is 25.9 ns against a 2.0 ns half-eye — over by a factor of 13. The link demonstrably works, so jitter here does not accumulate.
Corollary 2 (feasibility bound). A link is feasible for N-edge frames only if sigma < (UI/2) / Phi^-1(1 - eps/(2N)). At UI = 4 ns and MTU that ceiling is 430 ps for a 1% frame-error rate and 318 ps for 1e-6.

Reading 470 ps as a per-edge sigma appears to violate that bound — and that reading was wrong

Taken as an i.i.d. per-edge RMS, sigma = 470 ps exceeds the MTU ceiling by 9% at a 1% frame-error rate and by 48% at 1e-6, and centring perfectly (m = UI/2 = 2 ns) gives m/sigma = 4.26, so P(edge error) = 2.1e-5. Propagated over a frame that predicts:

FrameEdges NPredicted frame-error rate at ideal centring
ARP 64 B1280.27%
ICMP 98 B1960.41%
512 B10242.11%
1024 B20484.19%
MTU 1514 B30286.13%

A 6% loss rate on full frames would be survivable — TCP retransmits and the link still looks up. But it is not what a working gigabit link looks like, and the resolution turns out to be simpler than any of that.

Theorem 2 — the dual-Dirac split, and the contradiction dissolves

The standard decomposition splits jitter into a bounded deterministic part and an unbounded Gaussian random part, and combines them at a target bit-error rate: TJ = DJ_pp + 2n * RJ_rms, with n = 6.4 at 1e-10, 7.0 at 1e-12, 7.6 at 1e-14. A scope quotes total jitter. I had read 470 ps as a per-edge RMS sigma. Those are not the same number.

Target BERnRJ_rms if DJ_pp = 0RJ_rms if DJ_pp = 300 ps
1e-106.436.7 ps13.3 ps
1e-127.033.6 ps12.1 ps
1e-147.630.9 ps11.2 ps

Eye opening = 4000 - 470 = 3530 ps, which is 88% of the unit interval. Comfortably feasible. Read as an i.i.d. per-edge RMS, 470 ps implies a random component about 14x larger than the dual-Dirac decomposition allows at 1e-12. The feasibility violation was an artefact of my reading, not a property of the link. Corollary 2 remains true as stated; its premise simply does not hold here.

So the first question to ask about any jitter figure is: RMS or peak-to-peak, and at what BER? Everything downstream turns on that one answer.

Theorem 3 — bounded deterministic jitter, offered as a hypothesis and not a law

If the random component is only ~30 ps RMS it cannot explain frame-length dependence at all. Something bounded and pattern-dependent must: inter-symbol interference and duty-cycle distortion are functions of the bit pattern, not of elapsed time. A short ARP frame may never exercise the worst-case pattern; an MTU frame probably does. With p the per-edge probability of hitting a near-worst pattern, m(N) = s_inf - (s_inf - s0)(1-p)^N, which saturates rather than diverging — and the observed 26, 30, 31 does decelerate.

That fit is worth nothing as evidence and I want to be explicit about why. Three parameters against three points is exact by construction. Two diagnostics say so: the fitted ceiling lands on exactly 31.00 taps, but the MTU point is censored at 31, so any saturating model is forced there; and the fitted s0 comes out at -73 taps, a negative delay, which is what an over-parameterised fit looks like when nothing constrains it. Theorem 3 is a mechanism hypothesis with a prediction — 128 B should need about tap 30.8, and 256 B and above should already be pinned at 31. It is falsified if 256 B works comfortably at tap 28.

The experiment to run first: vary content, not length

A length sweep is confounded by the censored tap range. Payload content is not. Hold the frame at 1514 bytes and vary only the payload — all-zeros, all-ones, PRBS-7, PRBS-31, and a deliberate worst-case ISI pattern (a long run followed by an isolated transition) — 1e5 frames each at a fixed tap.

This needs no wider tap range and no new hardware, which is what makes it the first test rather than the third.

The three measured points cannot settle it. Fitting step against ln N gives consecutive slopes of 9.39 and 0.37 — a factor of 26 apart; against sqrt(N) it is 1.49 and 0.02, a factor of 61. Neither functional form fits, and the reason is visible in the data: the MTU point sits at tap 31, the maximum of the range, so it is right-censored. Its true required skew may be larger than the hardware can express.

The experiment that would settle it

Sweep the payload at 64, 128, 256, 512, 1024 and 1514 bytes at the best tap, 1e5 frames each, and measure frame-error rate directly instead of inferring it from whether the link comes up.

A widened tap range would also uncensor the MTU point. Until then the practical rule stands on its own evidence — calibrate to the longest frame — while the mechanism behind it stays open.

Reproduction

# synthesis
yosys -p 'synth_xilinx -flatten -nowidelut -family xc7 -json <top>.json' <sources>.v

# place and route
nextpnr-xilinx --chipdb <part>.bin --xdc <constraints>.xdc \
               --json <top>.json --write <top>_routed.json --fasm <top>.fasm

# bitstream
python3 fasm2frames.py --part <part> --db-root <prjxray-db> <top>.fasm > <top>.frames
xc7frames2bit --part_file <part>.yaml --frm_file <top>.frames --output_file <top>.bit

# flash
openFPGALoader -b <board> <top>.bit

The transmit skew is a PHY register written over MDIO, in steps of 0.06 ns; the 26-to-31 span is five steps, about 300 ps. Three traps in this flow are worth knowing: synth_xilinx takes -family xc7, not -arch; prjxray fasm2frames must run in-tree with PYTHONPATH set, because it is usually not pip-installed; and --db-root is the family directory, never the part directory. One more cost real time: a failed fasm2frames still leaves a partial .frames, from which xc7frames2bit will happily build a normal-looking 9.7 MB bitstream that flashes with done=1 and leaves the board silent. Check the exit status, not the file size — and done=1 means configuration completed, not that your design is on the board.

What this means

A fully open cycle — synthesis, place and route, bitstream, flashing, all local and unlicensed — takes gigabit Ethernet to a working state on Artix-7. Six places where it could not are now described and patched; one blocker remains open and is worked around at the cost of jitter.

This is not a replacement for Vivado. It is a report that on one class of design the open flow reaches the end, plus the exact list of what has to be fixed to get there.

What this does not settle

Receipts

Every figure above is measured, and the limits are named with it.
