tri x7-audit · the whole bitstream path, re-checked

One command re-runs every sweep: CRC 12/12 over 6 reference bitstreams, ECC 32520/32520 frames, FAR walk = Vivado FDRI, 82/82 pins, 4224/4224 segbits, writer 16/16 and fasm 22/22 byte-identical to xc7frames2bit and fasm2frames, gold 5/5. audit: CLEAN.

trinity-fpga $ tri x7-audit
ok CRC sweep 12/12 over 6 references
ok ECC sweep 32520/32520 frames
ok FAR walk 32520 frames = Vivado FDRI, 72/72 pad frames empty
ok pin sweep 82/82 constrained pins land in IOB frames with data
ok segbits sweep 4224/4224 set bits named by a tile's segbits at their walked frame
ok writer sweep 16/16 .bit byte-identical to xc7frames2bit (FDRI = original on 8), wrong-part input refu
sed
ok fasm sweep 22/22 .frames byte-identical to fasm2frames, refuse rows refused, --strict as expected (ou
rs 37.03 s, fasm2frames 150.7 s when the corpus was built)
ok gold (fpga-assembler #49) 5/5 frames = gold.frames, error text = reference
audit: CLEAN
trinity-fpga $

recorded 2026-10-04 03:38 UTCreal 208.3 sshown 13.3 sexit codes 0

$ tri x7-audit

Staged: the prompt and the typing. Real: every byte the commands printed, at the time they printed it. Any silence longer than 2 s is shown for 2 s, and the title bar says so while it happens. Edited: home directory shown as ~.
