tri fpga-txhold · RGMII margins from nextpnr's own SDF

Two recorded model runs (2026-09-27 and 09-28), printed: smallest TX hold 3445 ps on eth_txd[1], smallest RX mid-nibble margin 10900 ps on rxctl_n, both PASS. A model over the routed design's SDF, not a board measurement.

rxd_n[0]   mid-nibble: C   3680.0  D   1194.0  Delta   2486.0  Tsu  100.0 Th  100.0 ps; setup  17886.0 >
= 1000; hold  10914.0 >= 1000
rxd_n[1]   mid-nibble: C   3680.0  D   1247.0  Delta   2433.0  Tsu  100.0 Th  100.0 ps; setup  17833.0 >
= 1000; hold  10967.0 >= 1000
rxd_n[2]   mid-nibble: C   3680.0  D   1290.0  Delta   2390.0  Tsu  100.0 Th  100.0 ps; setup  17790.0 >
= 1000; hold  11010.0 >= 1000
rxd_n[3]   mid-nibble: C   3680.0  D   1293.0  Delta   2387.0  Tsu  100.0 Th  100.0 ps; setup  17787.0 >
= 1000; hold  11013.0 >= 1000
rxctl_n    mid-nibble: C   3680.0  D   1180.0  Delta   2500.0  Tsu  100.0 Th  100.0 ps; setup  17900.0 >
= 1000; hold  10900.0 >= 1000
rxd_p1[0]  at the rising edge: C   3680.0  D   1246.0  Delta   2434.0 ps; new for x <= 2334.0, old for x
 >= 2534.0; over the range new, at nominal new
rxd_p1[1]  at the rising edge: C   3680.0  D   1209.0  Delta   2471.0 ps; new for x <= 2371.0, old for x
 >= 2571.0; over the range new, at nominal new
rxd_p1[2]  at the rising edge: C   3680.0  D   1394.0  Delta   2286.0 ps; new for x <= 2186.0, old for x
 >= 2386.0; over the range new, at nominal new
rxd_p1[3]  at the rising edge: C   3680.0  D   1393.0  Delta   2287.0 ps; new for x <= 2187.0, old for x
 >= 2387.0; over the range new, at nominal new
rxctl_n    at the rising edge: C   3680.0  D   1180.0  Delta   2500.0 ps; new for x <= 2400.0, old for x
 >= 2600.0; over the range new, at nominal new
rxctl_n    at an RX_ER nibble's falling-edge change: new for x <= 2400.0, old for x >= 2600.0; over the
range new, at nominal new
guess (information only): verdict PASS; ed over the range undetermined, at nominal new; RX_ER over the r
ange undetermined, at nominal new
model (information only): ed over the range new, at nominal new; RX_ER over the range new, at nominal ne
w
smallest mid-nibble margin 10900.0 ps on rxctl_n
end: load average 9.93 6.25 7.33 on 8 cpus
VERDICT: PASS
trinity-fpga $

recorded 2026-10-03 19:49 UTCreal 4.7 sshown 4.7 sexit codes 0 0

$ tri fpga-txhold $ tri fpga-rxcap

Staged: the prompt and the typing. Real: every byte the commands printed, at the time they printed it. Any silence longer than 2 s is shown for 2 s, and the title bar says so while it happens. Edited: home directory shown as ~.
