t27c on mmcm.t27 -- the MMCM model, native

t27c 0.4.0 on a laptop (macOS): 16 tests pass natively -- VCO window, M/D/O ranges, fractional multiply in eighths, the 1/56 VCO-period phase step, and the lock window.

files $ t27c --version
t27c 0.4.0
files $ t27c test-report specs/fpga/mmcm.t27 --specs-dir specs
--- test report: specs/fpga/mmcm.t27 ---

  tests       16
  pass        16
  FAIL        0
  invariants  4   proved -- comptime, so compiling IS the check
  rate    100.0%

  runtime asserts executed, per test (#6509; a pass with 0 is vacuous, T730):
       2  vco_multiplies_the_input
       2  clkout_divides_the_vco
       2  divclk_divides_first
       2  mult_moves_in_eighth_steps
       2  vco_below_the_window_is_rejected
       2  vco_above_the_window_is_rejected
       2  a_legal_100mhz_request_passes
       1  vco_out_of_range_is_an_error
       2  zero_divclk_is_an_error
       1  mult_above_64_is_an_error
       1  input_above_the_window_is_an_error
       2  phase_step_is_one_fifty_sixth_of_the_vco
       3  a_faster_vco_gives_a_finer_phase_step
       1  lock_arrives_within_the_window
       1  lock_does_not_arrive_early
       3  relock_drops_the_lock
  vacuous passes  0 of 16  (passed with 0 runtime asserts executed)
files $

recorded 2026-10-07 17:34 UTCreal 8.7 sshown 8.6 sexit codes 0 0

$ t27c --version $ t27c test-report specs/fpga/mmcm.t27 --specs-dir specs

Staged: the prompt and the typing. Real: every byte the commands printed, at the time they printed it. Any silence longer than 2 s is shown for 2 s, and the title bar says so while it happens. Edited: home directory shown as ~.
