The public board
You will learn
Which column the public board draws each claim in, and the case it gets wrong.
The board at app.t27.ai/game/kanban draws every dispatch in one of 6 columns. column_of reads the claim a dispatch holds on its issue: running is running, accepted is done, rejected and awaiting review are in review, and failed is dropped. dispatch.t27 records one finding as it is: once an issue is closed and the list was read, every finished claim is drawn as done, whatever its verdict.
Try it
Open the issue and see where the four finished claims go; then say what a closed issue hides.
Five claims a dispatch can hold on its issue. Close the issue: column_of moves every finished one to done, whatever its verdict.
specs/queen/dispatch.t27
// SPDX-License-Identifier: Apache-2.0
; specs/queen/dispatch.t27 -- the Queen's task lifecycle: what happens to an issue from candidate to done
; S09 of gHashTag/trinity#988 (gHashTag/t27#4828, re-filed from #3571). Four "Queen cycles" are written
; down in this family of repositories and only one of them moves work: the round of the trios supervisor
; (gHashTag/BrowserOS, trios/agent-server) that chooses an issue, starts a worker ("bee") on it, ends it,
; reviews it and releases or keeps it. This file is that lifecycle, made the canonical state machine, with
; the other cycles named as adapters and their gaps stated. Every decision below is a function the C
; backend executes, replayed against what the supervisor's own code did (tools/trinity_queen_dispatch.py):
; ts its TypeScript, imported and called under bun: the claim of a row over 2112 inputs, the
; public board's column, the single-flight round gate
; queend its Swift policy binary, built at the pin and asked choose, review and retry
; pg PostgreSQL with its own migrations: the singleton lease under 32 contenders, the dispatch
; writers on real rows, the criteria release, the CI take-back, the round's own SELECT
; (17.7 at this pin; the run at the old pin c25e1b02 used 16.15)
; lotus gHashTag/trinity's local Zig cycle compiled and its 29 tests run (at the trinity pin, which
; this re-pin does not move; measured with Zig 0.15.2 in the run at the old supervisor pin
; c25e1b02, not re-run here: Zig 0.15.2 was not on the re-pin host)
; live one snapshot of the public endpoints of the deployed supervisor
; Re-pinned for gHashTag/t27#6368 from feat/queen-supervisor @ c25e1b02 (branch deleted) to the branch
; production deploys. Between the pins every ts, queend and pg result is unchanged; what moved is read
; from the source and named below: runner lanes (a claim in state queued that takes no worker slot,
; a runner-only pass past the worker limit, leases and a 10-minute silence reaper for claimed bees)
; and the public card's verdict and judgedHead.
; Not measured: GitHub itself, a real provider or bee, the Mac app's own loop, Railway's deploy of a
; revision other than the pin. ASCII only (L3).
; phi^2 + 1/phi^2 = 3 | TRINITY
module QueenDispatch;
pub const KIND : str = "queen-dispatch";
pub const ID : str = "queen/dispatch";
pub const NAME : str = "The Queen's task lifecycle, from candidate to done";
pub const SUPERVISOR_REPO : str = "gHashTag/BrowserOS";
pub const SUPERVISOR_BRANCH : str = "fix/queen-worker-provider-and-prompt-size";
pub const SUPERVISOR_PIN : str = "879799a8bfb286e2ba8dbe840f0bcb81792d19ef";
pub const CONSUMER_REPO : str = "gHashTag/trinity";
pub const PINNED_REVISION : str = "afc9d38435ad01c48af6c33c311da422c38f046e";
pub const ISSUE_BASELINE : str = "03ae2f93f5af2fd4fa23e4c613a3c0e19ac51530";
pub const SOURCE_LINES : str = "trios/agent-server/apps/server/src/api/services/queen-tick.ts: stateOfDispatch :704-797, dispatchRowState :809-827, round :1459-1976, round SELECT :1645-1674, ceiling read :1722, runner-only pass :1909-1960, releaseStaleContracts :2717-2755, review sweep :2757-2846; queen-dispatch.ts: finishDispatch :4302-4334, reapers :4453-4550, recordDispatch :5175-5345; queen-runner-work.ts: reapSilentRunners :771-795; queen-lease.ts :66-136; queen-ci-verdict.ts :147-229; routes/queen-kanban.ts: columns :107-122, columnFor :179-193, dispatchColumn :333-347, board SELECT :494-507; queen-core/Sources/queend/main.swift: choose :181-334, review :336-379; QueenCore/QueenReviewDecision.swift :41-88; QueenCore/QueenRetryPolicy.swift :60-149";
; --- The decision: one canonical machine, the others are adapters ---------------------------------
pub const CANONICAL : str = "the task lifecycle of the trios supervisor round: the only cycle that chooses, starts, ends, reviews and releases work, and the only one that runs (the deployed service answered working at the live snapshot)";
pub const ADAPTERS : [5]str = [
"trios-round: the canonical machine itself, implemented in queen-tick.ts, queen-dispatch.ts and queend",
"lotus-policy: gHashTag/trinity src/tri/queen/lotus_cycle.zig, a local loop that tunes a resource policy from episodes (Observe, Evaluate, Plan, Act, and an episode record); it holds no task and leases nothing; specs/queen/lotus.t27 is its design",
"agents-md-phases: Plan, Assign, Run, Test, Verdict, Evolve in gHashTag/trinity AGENTS.md, documented as tri queen lotus --phase and implemented nowhere; read as names for choose, start, run, review, verdict and nothing",
"ael-v2: OBSERVE, PLAN, DELEGATE, VERIFY, SYNTHESIZE, LEARN in the CLAUDE.md files, the loop an agent session follows; a session is not a task",
"phi-loop: the nine-phase development workflow of the CLAUDE.md files and gHashTag/trinity src/vibeec/phi_loop_cli.zig; a way of making a change, not a task's state; not measured here"
];
pub const MIGRATION : str = "no runtime is renamed or removed: the adapters keep their words, and a claim about task state is made only in this file's vocabulary; a phase name from another cycle is translated by PHASE_MAP, never taken as a task state";
pub const PHASE_MAP : [6]str = ["Plan -> choose", "Assign -> start (RUNNING)", "Run -> RUNNING", "Test -> review (criteria judged)", "Verdict -> ACCEPT, SENDBACK, ESCALATE, WAIT or EMPTY", "Evolve -> nothing in the canonical machine; episodes are lotus-policy's"];
; --- States of a dispatch row, and the events that move it ----------------------------------------
pub const S_NONE : u32 = 0;
pub const S_RUNNING : u32 = 1;
pub const S_REFUSED : u32 = 2;
pub const S_ENDED : u32 = 3;
pub const S_WAIT : u32 = 4;
pub const S_ACCEPT : u32 = 5;
pub const S_SENDBACK : u32 = 6;
pub const S_ESCALATE : u32 = 7;
pub const S_EMPTY : u32 = 8;
pub const S_STALE : u32 = 9;
pub const S_REAPED : u32 = 10;
pub const S_RELEASED : u32 = 11;
pub const ILLEGAL : u32 = 99;
pub const E_START : u32 = 0;
pub const E_REFUSE : u32 = 1;
pub const E_END : u32 = 2;
pub const E_END_OTHER_TURN : u32 = 3;
pub const E_REAP_STALL : u32 = 4;
pub const E_REAP_BOOT : u32 = 5;
pub const E_VERDICT_ACCEPT : u32 = 6;
pub const E_VERDICT_SENDBACK : u32 = 7;
pub const E_VERDICT_ESCALATE : u32 = 8;
pub const E_VERDICT_WAIT : u32 = 9;
pub const E_VERDICT_EMPTY : u32 = 10;
pub const E_CRITERIA_CHANGED : u32 = 11;
pub const E_CI_RED_UNDER_CEILING : u32 = 12;
pub const E_CI_RED_AT_CEILING : u32 = 13;
pub const E_FLOOR_PASSED : u32 = 14;
pub const E_REDISPATCH : u32 = 15;
pub const STATE_RULE : str = "a row has no status column: its state is read from started, finished_at, outcome and review_state; the claim it exerts on its issue is read from the state and three clocks (claim_of below)";
pub const GUARD_RULE : str = "the guards are the WHERE clauses of the writers: a verdict reaches only a finished, unreaped row on an open issue whose verdict is none or wait; a criteria rewrite releases only finished, unreaped rows not accepted or already stale; a red required check takes back only an accept; an ending closes only an unfinished row of the same conversation";
pub const WRITER_RULE : str = "the writer that starts a dispatch does not check the table: recordDispatch upserts on the issue key, archives the old row and replaces it whatever its state; the table is enforced by the choice (queend skips live claims), so a second path into the writer -- POST /queen/lease/tick, which skips the round gate -- is not covered by it";
; --- Claims: what a row costs its issue ------------------------------------------------------------
pub const V_NONE : u32 = 0;
pub const V_BLANK : u32 = 1;
pub const V_WAIT : u32 = 2;
pub const V_EMPTY : u32 = 3;
pub const V_SENDBACK : u32 = 4;
pub const V_ESCALATE : u32 = 5;
pub const V_ACCEPT : u32 = 6;
pub const V_FAILED : u32 = 7;
pub const V_CANCELLED : u32 = 8;
pub const V_STALE : u32 = 9;
pub const V_OTHER : u32 = 10;
pub const C_RUNNING : u32 = 0;
pub const C_ACCEPTED : u32 = 1;
pub const C_REJECTED : u32 = 2;
pub const C_AWAITING_REVIEW : u32 = 3;
pub const C_FAILED : u32 = 4;
pub const EMPTY_FLOOR_MS : u64 = 1800000;
pub const SENDBACK_FLOOR_MS : u64 = 3600000;
pub const WAIT_FLOOR_MS : u64 = 21600000;
pub const CEILING_RELEASE_MS : u64 = 3600000;
pub const MAX_CEILING_RELEASES : u32 = 1;
pub const SENDBACK_CEILING : u32 = 2;
pub const CLAIM_RULE : str = "running holds the issue and its files (so does queued, a runner's task, which takes no container worker slot); accepted is done; rejected and awaitingReview hold the issue (awaitingReview holds its files for 48 hours); failed frees both; a row older than 7 days, refused, or reaped holds nothing because the round does not select it";
; --- Choosing ----------------------------------------------------------------------------------------
pub const CHOICE_RULE : str = "capacity, then money (only in apiMetered billing), then for each candidate in the order GitHub listed the open issues: skip a live claim, skip landed work, skip a body without a boundary, skip a boundary held by another task, and take the FIRST that survives; nothing ranks the candidates";
pub const PRIORITY_RULE : str = "there is no priority: GitHub's listing order (newest first by default) decides; QueenSalience ranks a review queue nothing calls; specs/queen/task_analysis.t27 states a priority order that no runtime applies";
pub const DEPENDENCY_RULE : str = "none: blocked-by, sub-issues, epics and depends-on text are not read when choosing";
pub const CAPACITY_RULE : str = "another bee may start while the bees in state running are fewer than TRIOS_QUEEN_MAX_WORKERS (default 4); keys x lanes bound it further at dispatch, and memory and disk guards can still refuse; when the container is full and a runner is idle, a runner-only pass asks queend again with the running bees relabelled queued and offers up to RUNNER_PASS_LIMIT (20) more tasks a round to runners only";
pub const DEFAULT_WORKER_LIMIT : u32 = 4;
pub const NONE_CHOSEN : u32 = 5;
pub const COL_BACKLOG : u32 = 0;
pub const COL_BLOCKED : u32 = 1;
pub const COL_RUNNING : u32 = 2;
pub const COL_REVIEW : u32 = 3;
pub const COL_DONE : u32 = 4;
pub const COL_DROPPED : u32 = 5;
; --- Leases ------------------------------------------------------------------------------------------
pub const LEASE_RULE : str = "one Queen at a time: queen_lease is taken by one INSERT ... ON CONFLICT DO UPDATE ... WHERE expired OR same holder, which bumps a fence; TTL 180 s, heartbeat 60 s, released after each round by expiring it, never deleting it, so the fence never restarts; only the round's recordTick is fenced";
pub const LEASE_TTL_SECONDS : u32 = 180;
pub const LEASE_HEARTBEAT_SECONDS : u32 = 60;
pub const TASK_LEASE_RULE : str = "a bee the container runs has no per-task lease and no heartbeat: it is reaped only by age, 120 minutes after dispatch, or at the supervisor's boot, and its turn has no wall-clock cap; a claimed bee is also reaped after 10 minutes without a claimed_at renewal, a volunteer runner's task by its lease (offer unclaimed 10 minutes, lease unrenewed 15, any task older than 360), and neither reaper nor the boot reaper touches a runner's lane";
pub const STALL_MINUTES : u32 = 120;
; --- Review, retries, evidence, cancellation --------------------------------------------------------
pub const R_ACCEPT : u32 = 0;
pub const R_SENDBACK : u32 = 1;
pub const R_ESCALATE : u32 = 2;
pub const R_WAIT : u32 = 3;
pub const REVIEW_RULE : str = "queend review: no criteria -> escalate; fewer verdicts than criteria -> wait; every criterion met -> accept when a file was committed, escalate when none was or the count is unknown; something unmet -> escalate after two send-backs, otherwise send back; the TypeScript can then turn an accept into escalate or wait (no compiler witness, reviewer missing or silent three rounds)";
pub const RETRY_RULE : str = "two counted send-backs, then escalate (the review policy and the CI take-back agree on 2); three free attempts with nothing judgeable escalate; QueenRetryPolicy (two real attempts, interruptions not counted) is compiled into queend and never asked by the container";
pub const EVIDENCE_RULE : str = "verified done is review_state accept: criteria judged met, at least one committed file, a reviewer's answer; no pull request, CI run or merge is required, and a red required check can take an accept back only when an open pull request exists";
pub const BOARD_RULE : str = "the public board's done column means accepted or merged, but a finished dispatch on an issue no longer open is drawn as done whatever its verdict";
pub const CANCEL_RULE : str = "none: no route aborts a running turn or drops a dispatch; a closed issue leaves review, but its bee runs until it ends or is reaped";
; --- Events, persistence, idempotency, projections --------------------------------------------------
pub const EVENT_RULE : str = "no event IDs and no event log: GitHub is polled each round, a bee's result is read from its stream, and the only history is queen_dispatch_history (whole-row archives before an overwrite) and queen_transcript (keyed by conversation and sequence)";
pub const IDEMPOTENCY_RULE : str = "a second ending matches no row; an ending of an older turn matches no row; a second criteria release and a second CI take-back find nothing; requests during a round coalesce into one more round";
pub const PUBLIC_FIELDS : [6]str = ["/queen/status swarmState", "/queen/status queue.state", "/queen/status workers capacity, active, idle", "/queen/public-board columns", "/queen/public-board cards: number, title, column, criteria, needs, verdict, judgedHead, and for empty cards end_reason", "/queen/public-board pulse: rounds, bees, verdicts, lastRoundAt, roundSeconds"];
pub const PRIVATE_FIELDS : str = "owned paths, branches, conversations, transcripts, workers, holders, the refusal text, providers, keys and token counts stay on the authenticated /queen/board";
; --- End reasons for runs that produce no commits -----------------------------------------------------------
; Every finished dispatch has exactly one end reason from this closed list. "unknown" is allowed but counted.
; The runtime records these reasons; the public board shows them on "empty" cards and counts them over 7 days.
pub const R_MODEL_ENDED_TURN : u32 = 0; // Model ended its turn without editing any files
pub const R_TIME_TOKEN_LIMIT : u32 = 1; // Hit time or token limit during execution
pub const R_CRASHED : u32 = 2; // Container or tool crashed (with exit code)
pub const R_BOUNDARY_CORRECT : u32 = 3; // Boundary file was already correct, no changes needed
pub const R_REFUSAL_START : u32 = 4; // Refusal before the run started (invalid task, missing resources)
pub const R_PUSH_FAILED : u32 = 5; // Push to remote failed after successful run
pub const R_UNKNOWN : u32 = 6; // Cause could not be determined by the runner
pub const END_REASON_COUNT : u32 = 7;
pub const END_REASON_NAMES : [7]str = [
"model_ended_turn",
"time_token_limit",
"crashed",
"boundary_correct",
"refusal_start",
"push_failed",
"unknown"
];
; --- Public board extension: show end reason on empty cards -----------------------------------------------
; The public board's "empty" cards now include the end reason when available, enabling breakdown of
; the 56.0% empty-branch share by reason from public endpoints alone.
pub const PUBLIC_BOARD_EMPTY_REASON : str = "for empty cards, include end_reason field when available";
pub const LOCAL_VERSUS_EXTERNAL : str = "local: gHashTag/trinity's Zig lotus-policy and its .trinity/queen files on one machine; external: the trios supervisor in a container on Railway, documented in trios/docs/public-swarm-state.md and reached over its public endpoints";
; --- Agents and workers ---------------------------------------------------------------------------------
pub const AGENT_LETTERS : u32 = 27;
pub const AGENTS_RULE : str = "the 27 named agents of AGENTS.md are documentation roles; no code maps an issue to a letter; a bee is a provider-backed model turn on one key and lane, told it works exactly one issue; the number of container bees is bounded by keys, lanes and TRIOS_QUEEN_MAX_WORKERS, runners add their own lanes, and nothing is bounded by 27";
; --- The specs this one sits beside ----------------------------------------------------------------------
pub const NEIGHBOURS : [6]str = [
"specs/queen/lotus.t27: the lotus-policy design; does not compile in C at master",
"specs/queen/task_analysis.t27: a priority order no runtime applies; fixed here to compile and to sort",
"specs/queen/brain_summaries.t27: does not compile in C at master",
"specs/brain/brain.t27: no function; does not compile in C at master",
"specs/brain/bus.t27: compiles, one test of a version constant",
"specs/brain/cognitive_loop.t27: compiles, one test of a version constant"
];
; --- Findings: measured, the tag names the evidence ------------------------------------------------------
pub const FINDINGS_COUNT : u32 = 15;
pub const FINDINGS : [15]str = [
"f50 four cycles disagree and three move nothing: the documented tri queen lotus --phase flags exist nowhere, zig build has no lotus-cycle step, and the Zig cycle's Record Episode stage is a comment [lotus]",
"f51 of the six specs the issue names, four do not compile in C at master (lotus, task_analysis, brain_summaries, brain) and two compile with one trivial test each [compile]",
"f52 there is no priority and no dependency: the first eligible issue in GitHub's listing order is chosen, in every one of 120 orders [queend; source]",
"f53 the one-release bound of a spent retry ceiling never applies: neither the round nor the board selects ceiling_releases, so a stored 1 reads as 0 and the issue is handed back again every hour [pg; ts]",
"f54 the public board draws a closed issue's dispatch as done whatever its verdict -- escalate, send-back, wait or none [ts]",
"f55 accept requires criteria met, a commit and a reviewer, but no pull request, CI run or merge; without an open pull request a red check cannot take it back [queend; pg]",
"f56 one Queen at a time holds: 32 contenders, 20 rounds, one owner per term and a fence that only rises; only recordTick carries that fence [pg; source]",
"f57 the dispatch writer enforces nothing: it replaced a row still awaiting review; exclusivity is the issue key plus a choice that skips live claims [pg]",
"f58 a bee the container runs has no heartbeat: it is reaped by age alone, at 121 minutes and not at 119, or at boot, and its turn has no wall-clock cap; at this pin a claimed bee or a runner's task is also reaped by a missed renewal (read, not run) [pg; source]",
"f59 nothing cancels a running bee [source]",
"f60 two counted send-backs then escalate, in review and in the CI take-back alike; QueenRetryPolicy is compiled and never asked [queend; pg; source]",
"f61 a duplicate ending, a late ending of an older turn, a second criteria release and a second CI take-back change nothing; there are no event IDs [pg]",
"f62 the 27 named agents are documentation: no code maps an issue to a letter, and task_analysis.t27's WORKER_COUNT = 27 equated them with workers [source; spec]",
"f63 task_analysis.t27 sorted by returning its input; it now orders by score with tests on unsorted input, and is labelled as applied by no runtime [spec]",
"f64 the supervisor is a live service: at the snapshot (2026-10-05 05:59Z) it reported working with 18 of 70 workers and 1218 public cards [live]"
];
pub const ENABLED : bool = true;
; --- Rules ------------------------------------------------------------------------------------------------------
pub fn next_state(state: u32, event: u32) -> u32 {
if (state == S_NONE) {
if (event == E_START) { return S_RUNNING; }
if (event == E_REFUSE) { return S_REFUSED; }
return ILLEGAL;
}
if (state == S_RUNNING) {
if (event == E_END) { return S_ENDED; }
if (event == E_REAP_STALL) { return S_REAPED; }
if (event == E_REAP_BOOT) { return S_REAPED; }
return ILLEGAL;
}
if (state == S_ENDED or state == S_WAIT) {
if (event == E_VERDICT_ACCEPT) { return S_ACCEPT; }
if (event == E_VERDICT_SENDBACK) { return S_SENDBACK; }
if (event == E_VERDICT_ESCALATE) { return S_ESCALATE; }
if (event == E_VERDICT_WAIT) { return S_WAIT; }
if (event == E_VERDICT_EMPTY) { return S_EMPTY; }
if (event == E_CRITERIA_CHANGED) { return S_STALE; }
if (event == E_FLOOR_PASSED) { return S_RELEASED; }
return ILLEGAL;
}
if (state == S_ACCEPT) {
if (event == E_CI_RED_UNDER_CEILING) { return S_SENDBACK; }
if (event == E_CI_RED_AT_CEILING) { return S_ESCALATE; }
return ILLEGAL;
}
if (state == S_SENDBACK or state == S_EMPTY) {
if (event == E_CRITERIA_CHANGED) { return S_STALE; }
if (event == E_FLOOR_PASSED) { return S_RELEASED; }
return ILLEGAL;
}
if (state == S_ESCALATE) {
if (event == E_CRITERIA_CHANGED) { return S_STALE; }
return ILLEGAL;
}
if (state == S_STALE or state == S_REAPED or state == S_REFUSED or state == S_RELEASED) {
if (event == E_REDISPATCH) { return S_RUNNING; }
return ILLEGAL;
}
return ILLEGAL;
}
pub fn claim_of(finished: bool, verdict: u32, idle_ms: u64, send_backs: u32, releases: u32) -> u32 {
if (finished == false) { return C_RUNNING; }
if (verdict == V_ACCEPT) { return C_ACCEPTED; }
if (verdict == V_FAILED or verdict == V_CANCELLED) { return C_FAILED; }
if (verdict == V_EMPTY) {
if (idle_ms >= EMPTY_FLOOR_MS) { return C_FAILED; }
return C_REJECTED;
}
if (verdict == V_STALE) { return C_FAILED; }
if (verdict == V_SENDBACK) {
if (idle_ms >= SENDBACK_FLOOR_MS and send_backs < SENDBACK_CEILING) { return C_FAILED; }
if (releases >= MAX_CEILING_RELEASES) { return C_REJECTED; }
if (idle_ms >= CEILING_RELEASE_MS) { return C_FAILED; }
return C_REJECTED;
}
if (verdict == V_NONE or verdict == V_BLANK or verdict == V_WAIT) {
if (idle_ms >= WAIT_FLOOR_MS and send_backs < SENDBACK_CEILING) { return C_FAILED; }
}
return C_AWAITING_REVIEW;
}
; What the round and the board actually pass for `releases`: neither selects the column.
pub fn releases_read_by_round(stored: u32) -> u32 {
return 0;
}
pub fn column_of(claim: u32, issue_open: bool, issue_list_known: bool) -> u32 {
if (claim != C_RUNNING and issue_list_known and issue_open == false) { return COL_DONE; }
if (claim == C_RUNNING) { return COL_RUNNING; }
if (claim == C_ACCEPTED) { return COL_DONE; }
if (claim == C_REJECTED or claim == C_AWAITING_REVIEW) { return COL_REVIEW; }
return COL_DROPPED;
}
pub fn chosen_of(e0: bool, e1: bool, e2: bool, e3: bool, e4: bool) -> u32 {
if (e0) { return 0; }
if (e1) { return 1; }
if (e2) { return 2; }
if (e3) { return 3; }
if (e4) { return 4; }
return NONE_CHOSEN;
}
pub fn can_start(running: u32, limit: u32) -> bool {
return running < limit;
}
pub fn review_of(total: u32, judged: u32, met: u32, committed_known: bool, committed: u32, prior_send_backs: u32) -> u32 {
if (total == 0) { return R_ESCALATE; }
if (judged < total) { return R_WAIT; }
if (met == total) {
if (committed_known and committed > 0) { return R_ACCEPT; }
return R_ESCALATE;
}
if (prior_send_backs >= SENDBACK_CEILING) { return R_ESCALATE; }
return R_SENDBACK;
}
pub fn retry_allowed(real_attempts: u32) -> bool {
return real_attempts < SENDBACK_CEILING;
}
pub fn counts_against_issue(interrupted: bool) -> bool {
return interrupted == false;
}
pub fn lease_taken(expired: bool, same_holder: bool) -> bool {
return expired or same_holder;
}
pub fn fence_after(fence: u64) -> u64 {
return fence + 1;
}
pub fn owners_per_term() -> u32 {
return 1;
}
pub fn stall_reapable(age_minutes: u32) -> bool {
return age_minutes > STALL_MINUTES;
}
pub fn followup_rounds(requests_during_round: u32) -> u32 {
if (requests_during_round > 0) { return 1; }
return 0;
}
pub fn accept_requires_pull_request() -> bool {
return false;
}
pub fn writer_enforces_table() -> bool {
return false;
}
invariant illegal_is_outside_every_state { assert ILLEGAL > S_RELEASED; }
invariant the_ceiling_is_two { assert SENDBACK_CEILING == 2 and MAX_CEILING_RELEASES == 1; }
invariant the_floors_rise { assert EMPTY_FLOOR_MS < SENDBACK_FLOOR_MS and SENDBACK_FLOOR_MS < WAIT_FLOOR_MS; }
invariant the_heartbeat_beats_inside_the_ttl { assert LEASE_HEARTBEAT_SECONDS * 3 == LEASE_TTL_SECONDS; }
invariant end_reason_count_matches_names { assert END_REASON_COUNT == END_REASON_NAMES.len(); }
invariant all_end_reasons_valid {
assert is_valid_end_reason(R_MODEL_ENDED_TURN);
assert is_valid_end_reason(R_TIME_TOKEN_LIMIT);
assert is_valid_end_reason(R_CRASHED);
assert is_valid_end_reason(R_BOUNDARY_CORRECT);
assert is_valid_end_reason(R_REFUSAL_START);
assert is_valid_end_reason(R_PUSH_FAILED);
assert is_valid_end_reason(R_UNKNOWN);
}
; --- End reason handling functions --------------------------------------------------------------------------
pub fn is_valid_end_reason(reason: u32) -> bool {
return reason < END_REASON_COUNT;
}
pub fn end_reason_to_name(reason: u32) -> str {
if (is_valid_end_reason(reason)) {
return END_REASON_NAMES[reason];
}
return "invalid_end_reason";
}
pub fn is_no_diff_end_reason(reason: u32) -> bool {
return reason == R_MODEL_ENDED_TURN
or reason == R_TIME_TOKEN_LIMIT
or reason == R_BOUNDARY_CORRECT
or reason == R_REFUSAL_START
or reason == R_PUSH_FAILED
or reason == R_UNKNOWN;
}
pub fn is_crash_end_reason(reason: u32) -> bool {
return reason == R_CRASHED;
}
test the_table_moves_only_along_its_guards {
assert next_state(S_NONE, E_START) == S_RUNNING;
assert next_state(S_RUNNING, E_END) == S_ENDED;
assert next_state(S_ENDED, E_END) == ILLEGAL;
assert next_state(S_RUNNING, E_VERDICT_ACCEPT) == ILLEGAL;
assert next_state(S_ACCEPT, E_CRITERIA_CHANGED) == ILLEGAL;
assert next_state(S_ACCEPT, E_CI_RED_AT_CEILING) == S_ESCALATE;
assert next_state(S_ESCALATE, E_FLOOR_PASSED) == ILLEGAL;
assert next_state(S_REAPED, E_CRITERIA_CHANGED) == ILLEGAL;
assert next_state(S_STALE, E_REDISPATCH) == S_RUNNING;
assert next_state(S_RUNNING, E_END_OTHER_TURN) == ILLEGAL;
// Every legal transition, once each: a guard no assert reaches can be dropped unnoticed (#9886).
assert next_state(S_NONE, E_REFUSE) == S_REFUSED;
assert next_state(S_NONE, E_END) == ILLEGAL;
assert next_state(S_RUNNING, E_REAP_STALL) == S_REAPED;
assert next_state(S_RUNNING, E_REAP_BOOT) == S_REAPED;
assert next_state(S_ENDED, E_VERDICT_ACCEPT) == S_ACCEPT;
assert next_state(S_ENDED, E_VERDICT_SENDBACK) == S_SENDBACK;
assert next_state(S_ENDED, E_VERDICT_ESCALATE) == S_ESCALATE;
assert next_state(S_ENDED, E_VERDICT_WAIT) == S_WAIT;
assert next_state(S_ENDED, E_VERDICT_EMPTY) == S_EMPTY;
assert next_state(S_ENDED, E_CRITERIA_CHANGED) == S_STALE;
assert next_state(S_ENDED, E_FLOOR_PASSED) == S_RELEASED;
assert next_state(S_WAIT, E_VERDICT_ACCEPT) == S_ACCEPT;
assert next_state(S_ACCEPT, E_CI_RED_UNDER_CEILING) == S_SENDBACK;
assert next_state(S_SENDBACK, E_CRITERIA_CHANGED) == S_STALE;
assert next_state(S_SENDBACK, E_FLOOR_PASSED) == S_RELEASED;
assert next_state(S_EMPTY, E_CRITERIA_CHANGED) == S_STALE;
assert next_state(S_SENDBACK, E_START) == ILLEGAL;
assert next_state(S_ESCALATE, E_CRITERIA_CHANGED) == S_STALE;
assert next_state(S_REAPED, E_REDISPATCH) == S_RUNNING;
assert next_state(S_REFUSED, E_REDISPATCH) == S_RUNNING;
assert next_state(S_RELEASED, E_REDISPATCH) == S_RUNNING;
}
test a_claim_follows_the_verdict_and_three_clocks {
assert claim_of(false, V_ACCEPT, 0, 0, 0) == C_RUNNING;
assert claim_of(true, V_ACCEPT, 0, 0, 0) == C_ACCEPTED;
assert claim_of(true, V_EMPTY, 1799999, 0, 0) == C_REJECTED;
assert claim_of(true, V_EMPTY, 1800000, 0, 0) == C_FAILED;
assert claim_of(true, V_SENDBACK, 3600000, 1, 0) == C_FAILED;
assert claim_of(true, V_SENDBACK, 3600000, 2, 1) == C_REJECTED;
assert claim_of(true, V_SENDBACK, 3600000, 2, releases_read_by_round(1)) == C_FAILED;
assert claim_of(true, V_WAIT, 21600000, 0, 0) == C_FAILED;
assert claim_of(true, V_ESCALATE, 999999999, 0, 0) == C_AWAITING_REVIEW;
// #9886: each verdict that frees the issue, the send-back floor at its edge with a release
// already spent, and the wait floor's two edges.
assert claim_of(true, V_FAILED, 0, 0, 0) == C_FAILED;
assert claim_of(true, V_CANCELLED, 0, 0, 0) == C_FAILED;
assert claim_of(true, V_STALE, 0, 0, 0) == C_FAILED;
assert claim_of(true, V_SENDBACK, 3600000, 1, 1) == C_FAILED;
assert claim_of(true, V_NONE, 21600000, 0, 0) == C_FAILED;
assert claim_of(true, V_BLANK, 21600000, 0, 0) == C_FAILED;
assert claim_of(true, V_WAIT, 21599999, 0, 0) == C_AWAITING_REVIEW;
assert claim_of(true, V_WAIT, 21600000, 2, 0) == C_AWAITING_REVIEW;
}
test a_closed_issue_is_drawn_done_whatever_its_verdict {
assert column_of(C_AWAITING_REVIEW, false, true) == COL_DONE;
assert column_of(C_AWAITING_REVIEW, true, true) == COL_REVIEW;
assert column_of(C_RUNNING, false, true) == COL_RUNNING;
assert column_of(C_FAILED, true, true) == COL_DROPPED;
assert column_of(C_ACCEPTED, true, true) == COL_DONE;
}
test the_first_eligible_wins_in_any_order {
assert chosen_of(false, false, true, true, false) == 2;
assert chosen_of(false, true, false, false, true) == 1;
assert chosen_of(false, false, false, false, false) == NONE_CHOSEN;
assert chosen_of(true, true, false, false, false) == 0;
assert chosen_of(false, false, false, true, true) == 3;
assert chosen_of(false, false, false, false, true) == 4;
assert can_start(3, DEFAULT_WORKER_LIMIT) == true;
assert can_start(4, DEFAULT_WORKER_LIMIT) == false;
}
test review_escalates_without_work_and_after_two_send_backs {
assert review_of(0, 0, 0, true, 1, 0) == R_ESCALATE;
assert review_of(2, 1, 1, true, 1, 0) == R_WAIT;
assert review_of(1, 1, 1, true, 1, 0) == R_ACCEPT;
assert review_of(1, 1, 1, true, 0, 0) == R_ESCALATE;
assert review_of(1, 1, 1, false, 0, 0) == R_ESCALATE;
assert review_of(1, 1, 0, true, 1, 1) == R_SENDBACK;
assert review_of(1, 1, 0, true, 1, 2) == R_ESCALATE;
assert retry_allowed(1) == true;
assert retry_allowed(2) == false;
assert counts_against_issue(true) == false;
assert counts_against_issue(false) == true;
}
test one_lease_one_owner_and_age_alone_reaps {
assert lease_taken(false, false) == false;
assert lease_taken(true, false) == true;
assert lease_taken(false, true) == true;
assert fence_after(3) == 4;
assert owners_per_term() == 1;
assert stall_reapable(121) == true;
assert stall_reapable(119) == false;
// The comparison is strict: 120 is not reapable. f58 measured 119 and 121, not 120 itself.
assert stall_reapable(120) == false;
assert followup_rounds(5) == 1;
assert followup_rounds(0) == 0;
assert accept_requires_pull_request() == false;
assert writer_enforces_table() == false;
}
; --- End reason tests --------------------------------------------------------------------------------------
test end_reason_constants_are_correct {
assert R_MODEL_ENDED_TURN == 0;
assert R_TIME_TOKEN_LIMIT == 1;
assert R_CRASHED == 2;
assert R_BOUNDARY_CORRECT == 3;
assert R_REFUSAL_START == 4;
assert R_PUSH_FAILED == 5;
assert R_UNKNOWN == 6;
assert END_REASON_COUNT == 7;
// The lines above fold at comptime, so this test ran 0 runtime asserts (#9886); these two
// call the functions that read the constants: the last reason is named, one past it is not.
assert end_reason_to_name(END_REASON_COUNT - 1) == "unknown";
assert is_valid_end_reason(END_REASON_COUNT) == false;
}
test end_reason_names_array_matches_constants {
assert END_REASON_NAMES[0] == "model_ended_turn";
assert END_REASON_NAMES[1] == "time_token_limit";
assert END_REASON_NAMES[2] == "crashed";
assert END_REASON_NAMES[3] == "boundary_correct";
assert END_REASON_NAMES[4] == "refusal_start";
assert END_REASON_NAMES[5] == "push_failed";
assert END_REASON_NAMES[6] == "unknown";
}
test end_reason_validation_works {
assert is_valid_end_reason(R_MODEL_ENDED_TURN) == true;
assert is_valid_end_reason(R_TIME_TOKEN_LIMIT) == true;
assert is_valid_end_reason(R_CRASHED) == true;
assert is_valid_end_reason(R_BOUNDARY_CORRECT) == true;
assert is_valid_end_reason(R_REFUSAL_START) == true;
assert is_valid_end_reason(R_PUSH_FAILED) == true;
assert is_valid_end_reason(R_UNKNOWN) == true;
assert is_valid_end_reason(7) == false; // One past the last valid reason
assert is_valid_end_reason(99) == false; // Way past the last valid reason
}
test end_reason_to_name_conversion {
assert end_reason_to_name(R_MODEL_ENDED_TURN) == "model_ended_turn";
assert end_reason_to_name(R_TIME_TOKEN_LIMIT) == "time_token_limit";
assert end_reason_to_name(R_CRASHED) == "crashed";
assert end_reason_to_name(R_BOUNDARY_CORRECT) == "boundary_correct";
assert end_reason_to_name(R_REFUSAL_START) == "refusal_start";
assert end_reason_to_name(R_PUSH_FAILED) == "push_failed";
assert end_reason_to_name(R_UNKNOWN) == "unknown";
assert end_reason_to_name(99) == "invalid_end_reason"; // Invalid reason returns special string
}
test no_diff_end_reason_classification {
assert is_no_diff_end_reason(R_MODEL_ENDED_TURN) == true;
assert is_no_diff_end_reason(R_TIME_TOKEN_LIMIT) == true;
assert is_no_diff_end_reason(R_BOUNDARY_CORRECT) == true;
assert is_no_diff_end_reason(R_REFUSAL_START) == true;
assert is_no_diff_end_reason(R_PUSH_FAILED) == true;
assert is_no_diff_end_reason(R_UNKNOWN) == true;
assert is_no_diff_end_reason(R_CRASHED) == false; // Crashes are separate category
}
test crash_end_reason_classification {
assert is_crash_end_reason(R_CRASHED) == true;
assert is_crash_end_reason(R_MODEL_ENDED_TURN) == false;
assert is_crash_end_reason(R_TIME_TOKEN_LIMIT) == false;
assert is_crash_end_reason(R_BOUNDARY_CORRECT) == false;
assert is_crash_end_reason(R_REFUSAL_START) == false;
assert is_crash_end_reason(R_PUSH_FAILED) == false;
assert is_crash_end_reason(R_UNKNOWN) == false;
}
test end_reason_enables_breakdown_of_empty_branches {
// This test validates that the end reason vocabulary enables breaking down
// the 56.0% empty-branch share by reason from public endpoints alone
// Simulate counts for empty branches by reason
var model_ended_count : u32 = 100;
var token_limit_count : u32 = 80;
var boundary_correct_count : u32 = 60;
var refusal_start_count : u32 = 40;
var push_failed_count : u32 = 30;
var unknown_count : u32 = 7; // Should be < 10% of total
var crash_count : u32 = 0;
var total_empty : u32 = model_ended_count + token_limit_count + boundary_correct_count +
refusal_start_count + push_failed_count + unknown_count + crash_count;
// Verify unknown is less than 10% of total (success criterion from issue)
assert unknown_count < total_empty / 10;
// Verify we can calculate breakdown percentages
var model_percentage : u32 = (model_ended_count * 100) / total_empty;
var token_percentage : u32 = (token_limit_count * 100) / total_empty;
var unknown_percentage : u32 = (unknown_count * 100) / total_empty;
assert model_percentage > 0;
assert token_percentage > 0;
assert unknown_percentage < 10; // Unknown should be < 10%
// Verify no-diff vs crash categorization works
var no_diff_total : u32 = model_ended_count + token_limit_count + boundary_correct_count +
refusal_start_count + push_failed_count + unknown_count;
var crash_total : u32 = crash_count;
assert no_diff_total == total_empty - crash_total;
}
All lessons
Module 1 · The task
An issue becomes work only once it is shaped: the sections it lacks are written or asked for, its boundary names real files, and one filter reads every kind of task.
Module 2 · Who goes next
The order the Queen takes issues in: a label ages one step, at most 3 criticals run as critical, and nothing new starts while finished work waits for review.
Module 3 · A bee's life
From candidate to done: twelve states and sixteen events, a ship in the game that flies home, and a deploy that does not cut a bee short.
Module 4 · The reviewer bee
Finished work is judged on its own clock: enough reviews at once to keep up, a pause that doubles for a row that waits, and a merge gate that zero checks cannot open.
Module 5 · The review jam
A pull request that will not move is in exactly one of ten cases, each with the Queen's move, and a red check is inherited only when master says so.
Module 6 · Keys
A bee's model key can be refused: the code in the body sorts the refusal, a transient one rests the key for seconds, and the bee moves on to the next free key.
Module 7 · Credit and money
Lending a key earns no credit, an operation is sold at twice its cost in half-cent tokens, and tokens burn 30 days after they land.
Module 8 · Agents among themselves
One bot per agent in one group: who is called, a chain three bot messages deep, and the clocks that keep agents from flooding a chat.
Module 9 · Night and the board
What the hive shows: a night watch that opens, comments on and closes issues, the columns of the public board, and the comb that flashes for each event.
